PUMP, GEAR TRIPLE 6676971 (3)
1 6676971
- 6676971 - PUMP
- GEAR TRIPLE
- Assy. - W/Ref. 2-28 - (4 bolt flange) - Also Order 6807346 tee (3)
- 58K000210B o-ring (3)
- 73G000520B bolt (12)
- 4E000005B washer (12)
- 19J000008B clamp (6) - Was 6674941
2 6662925
- 6662925 - SNAP RING
3 6662926
- 6662926 - SEAL
- Incl. W/Ref. 29
4 6663978
- 6663978 - COVER
- front
5 6663979
- 6663979 - BEARING
6 6662929
- 6662929 - PIN
- DOWEL
- .403 inch (10
- 25mm) long
7 6670632
- 6670632 - SHAFT
- Drive
8 6673142
- 6673142 - SHAFT
- Drive
9 6662932
- 6662932 - COVER
- End
10 6663989
- 6663989 - PLATE
11 6665621
- 6665621 - DOWEL PIN
- .716 inch (18
- 20mm) long
12 6673135
- 6673135 - BLOCK
- Check valve
13 6673137
- 6673137 - PLUG
14 6673136
- 6673136 - VALVE
- CHECK
- Assy. - W/Ref. 26
15 6672515
- 6672515 - KIT
- SEAL
- Was 6673140
16 6673138
- 6673138 - PLUG ASSEMBLY
- W/Ref. 28
17 6673141
- 6673141 - O-RING
18 6673139
- 6673139 - SEAL KIT
- Includes Ref. 3 (1)
- 5 (6)
- 6 (6)
- 7 (6)
- 26 (2) & 28 (1)
