VALVE, SECTION
1 6660501
- 6660501 - VALVE
- SECTION
- Arm - See Ref. 2-12
2 6660742
- 6660742 - POSITIONER
- Spool - W/Ref. 5 & 6
3 6660743
- 6660743 - SEAL
4 6665439
- 6665439 - BOLT
- Was 73G000448B
5 6660744
- 6660744 - POSITONER
- Spool - W/Ref. 5 & 6
6 6651653
- 6651653 - VALVE
- RELIEF
- Set at 2950 PSI - W/Ref. 9 & 11-14
7 6647693
- 6647693 - SEAL KIT
8 6660745
- 6660745 - ORIFICE
- Assy. (.125 inch) - See Note
9 6660748
- 6660748 - SEAL
- Section block
10 896265
- 896265 - SHIM
- .010'' (0
- 25 mm) thick
11 896264
- 896264 - SHIM
- .020'' (0
- 5 mm) thick
12 896263
- 896263 - SHIM
- .040 (1
- 0 mm) thick
