341.0
/
VALVE, SECTION 6679924 (2)

VALVE, SECTION 6679924 (2)

VALVE, SECTION 6679924 (2)

1 6679924

  • 6679924 - VALVE
  • SECTION
  • right travel - W/ .750" press. ports - W/(3) O-ring grooves - Was 6686582

2 6677472

  • 6677472 - KIT
  • SEAL
  • not included with Ref. 1 - Was 6686594

3 6677699

  • 6677699 - ACTUATOR ASSEMBLY
  • assy - Was 6685254

4 6677470

  • 6677470 - SEAL KIT
  • assy - Was 6685264

5 6677467

  • 6677467 - KIT
  • SEAL
  • Was 6685259

6 6677690

  • 6677690 - KIT
  • COMPENSATOR
  • pressure - Was 6685237

7 6685248

  • 6685248 - PLUG
  • pressure

8 6677695

  • 6677695 - SCREW
