NUT, NYLOCK FLANGED 7028550 (4)

NUT, NYLOCK FLANGED 7028550 (4)

NUT, NYLOCK FLANGED 7028550 (4)

1 7028550

  • 7028550 - NUT
  • NYLOCK FLANGED

2 7023322

  • 7023322 - NUT
  • FLANGE
  • if equipped - use W/Ref. 6

3 7030073

  • 7030073 - GAS SPRING

4 7030076

  • 7030076 - BALL JOINT

5 7269530

  • 7269530 - PIN
  • if equipped - use W/Ref. 7

6 7030079

  • 7030079 - SCREW

7 7030071

  • 7030071 - GROMMET

8 7267443

  • 7267443 - GROMMET
  • if equipped - use W/Ref. 12

9 7030070

  • 7030070 - BUMPER
  • RUBBER

10 7260656

  • 7260656 - HANDLE
  • LATCH WINDSHIELD
  • if equipped - 2 grommet - use W/Ref. 3
  • 6
  • 7
  • & 10

11 7030075

  • 7030075 - SPRING
  • TORSION
  • LH

12 7030074

  • 7030074 - SPRING
  • TORSION
  • RH

13 7030078

  • 7030078 - PIN
  • PIVOT

14 7030077

  • 7030077 - SCREW

15 7027674

  • 7027674 - PLUG
  • WIPER

16 7030067

  • 7030067 - BRACKET
  • HINGE
  • Upper RH

17 7030066

  • 7030066 - BRACKET
  • HINGE
  • Upper LH

18 7030072

  • 7030072 - HANDLE
  • LATCH WINDSHIELD
  • 1 grommet - use W/Ref. 21

19 7275137

  • 7275137 - KIT
  • BRACKET
  • Ref. 3
  • 6 & 24

20 7258285

  • 7258285 - BRACKET
  • CENTERING
