SPRING 6610082 (1)
1 6610082
- 6610082 - SPRING
2 6664085
- 6664085 - BUSHING NYLON
- Use qty (1) on Ref. 17 (6684139) wiper motor
3 6664085
- 6664085 - BUSHING NYLON
- Use qty (2) on Ref. 17 ( 6679476) wiper motor
4 7188372
- 7188372 - BLADE
- WIPER WINDOW
- Use W/Ref. 18 (7234015 arm)
- Ref. 39 & 40
5 7147359
- 7147359 - BLADE
- WIPER WINDOW
- Use W/Ref. 18 (NLA 6680180 arm) & Ref. 7
6 6685140
- 6685140 - COVER
- motor - Use on Ref. 17 (6684139) wiper motor
7 6677836
- 6677836 - COVER
- motor - Use on Ref. 17 ( 6679476) wiper motor - Was 6685140
8 6677837
- 6677837 - BOLT
9 6677839
- 6677839 - GASKET
10 6677841
- 6677841 - WASHER
11 6677842
- 6677842 - NUT
12 6677843
- 6677843 - NUT
13 6677844
- 6677844 - NUT
- Use qty (1) on Ref. 17 (6684139) wiper motor
14 6677844
- 6677844 - NUT
- Use qty (2) on Ref. 17 ( 6679476) wiper motor
15 6677845
- 6677845 - ADAPTER
- Use W/NLA blade
16 6677847
- 6677847 - GROMMET
17 6678198
- 6678198 - BOLT
- Use on Ref. 17 ( 6679476) wiper motor
18 6678739
- 6678739 - WASHER M5 FLAT
- Use on Ref. 17 ( 6679476) wiper motor
19 6640699
- 6640699 - CONNECTOR METRI PACK
- electrical connector
20 6684139
- 6684139 - MOTOR
- WIPER
- Use with window W/2 holes
21 6679476
- 6679476 - MOTOR
- WIPER
- W/threaded shaft end & built in fuse
22 7234015
- 7234015 - ARM
- WIPER
- Use W/Ref. 4 (7188372 blade)
- 39 & 40
23 6680971
- 6680971 - RETAINER
24 6681651
- 6681651 - RING
- RETAINER
- retaining
25 6681652
- 6681652 - CAP PLUG
26 6589675
- 6589675 - SCREW
27 6801059
- 6801059 - WASHER NEOPRENE
- Use on Ref. 17 ( 6679476) wiper motor
28 6803202
- 6803202 - SCREW
29 6812413
- 6812413 - PIN
30 6812708
- 6812708 - FRAME
31 6813028
- 6813028 - ROLLER
32 6814423
- 6814423 - BRACKET LATCH
33 7178840
- 7178840 - BRACKET
- LATCH
- Was 6816437
34 6812710
- 6812710 - WINDOW
- front - 3 hole - Also Order (1) each of 6808882 adhesive
- 7102268 primer
- 7110861 cleaner
- 6903848 instruction
- and (12) 7101512 bumpers
35 21CM616
- 21CM616 - SCREW
36 30H10
- 30H10 - CLIP
37 43DM6
- 43DM6 - NUT FLANGED HEX
38 51DM6
- 51DM6 - NUT HX THDLK PREAPPL
39 6682492
- 6682492 - EDGE TRIM BULK/FT
- bulk - sold per foot
40 4DM5
- 4DM5 - NUT HEXAGON M5
41 6903848ENUS
- 6903848ENUS - INSTRUCTIONS
- Was 6903848
42 7110861
- 7110861 - CLEANER
- Not in kit - Order separately
43 7101512
- 7101512 - BUMPER
44 7230824
- 7230824 - ADHESIVE
- NON-PRIMER
- 0
- 31 L (10.5 oz) - Was 6808882
45 7110862
- 7110862 - KIT
- WINDOW
- front window install
46 7009047
- 7009047 - PLATE
- Use W/Ref. 18 (7234015 arm)
- Ref. 4 (7188372 blade)
- & 42
47 7188373
- 7188373 - SWIVEL
- PLATE ASSY
- Use W/Ref. 11 (7234015 arm)
- Ref. 25 (7188372 blade)
- & 31 - Was 7255629
