PLATE 6544004

PLATE 6544004

PLATE 6544004

1 6544004

  • 6544004 - PLATE
  • mounting

2 17C616

  • 17C616 - BOLT 5

3 61D6

  • 61D6 - NUT HEX FINISHED GR5

4 4E8

  • 4E8 - WASHER

5 6515535

  • 6515535 - TANK
  • LPG

6 715977

  • 715977 - COUPLER
  • Male

7 715976

  • 715976 - COUPLER
  • Female

8 6515605

  • 6515605 - ELEMENT
  • filter - W/6501945

9 6555113

  • 6555113 - ASSY
  • HOSE

10 618298

  • 618298 - ELBOW
  • street
