Bobcat
/
631.0
/
SUPPORT 6513874

SUPPORT 6513874

SUPPORT 6513874

1 6513874

  • 6513874 - SUPPORT

2 6513859

  • 6513859 - STUD

3 6630279

  • 6630279 - BUSHING

4 6513875

  • 6513875 - PLUG

5 1DM6

  • 1DM6 - NUT

6 6513863

  • 6513863 - HEX NUT

7 6630278

  • 6630278 - BUSHING

8 6513858

  • 6513858 - WASHER

9 6512579

  • 6512579 - LOCK WSHR

10 1DM10

  • 1DM10 - NUT

11 6647632

  • 6647632 - ARM
  • ROCKER
  • W/Ref. 3
  • 5 - 8
  • & 13 - Was 6513861

12 6513862

  • 6513862 - SCREW
  • ADJUSTING

13 6513854

  • 6513854 - PUSHROD

14 6513873

  • 6513873 - SEAL

15 6513856

  • 6513856 - TUBE

16 6513857

  • 6513857 - SPRING

17 6513855

  • 6513855 - SEAL
  • WASHER

18 6513872

  • 6513872 - SEAL

19 6513853

  • 6513853 - TAPPET

20 6513738

  • 6513738 - CAMSHAFT

21 6516067

  • 6516067 - WASHER
