SHUTDN KT 6705289 (3)

SHUTDN KT 6705289 (3)

SHUTDN KT 6705289 (3)

1 6705289

  • 6705289 - SHUTDN KT
  • Ref. 2 - 16

2 6651975

  • 6651975 - SWITCH
  • RELAY MAGNETIC

3 6703685

  • 6703685 - BRACKET

4 37C512

  • 37C512 - BOLT SQ NECK RND HD
  • Was 7C512

5 85D5

  • 85D5 - NUT PRETRQ HEX LOCK

6 85D4

  • 85D4 - NUT 5

7 6703686

  • 6703686 - HARNESS
  • chassis

8 17C412

  • 17C412 - BOLT 5

9 6667993

  • 6667993 - SOLENOID
  • fuel shut-off - Was 6577503

10 6578366

  • 6578366 - JOINT
  • BALL

11 6578363

  • 6578363 - ROD END

12 62D4

  • 62D4 - NUT HEX FINISHED GR5

13 6610510

  • 6610510 - STRAP
  • TIE 10

14 6703730

  • 6703730 - MOUNT

15 6714543

  • 6714543 - GASKET
  • Was 3974461B

16 5289686

  • 5289686 - PLUG
  • black - 0.38" dia hole

17 6669415

  • 6669415 - TIMER
  • SOLENOID

18 6702444

  • 6702444 - FUSE 25A 5
  • 25 amp - Was 6670808

19 6713879

  • 6713879 - HARNESS
  • 16'' (406
  • 4mm) long

20 6722357

  • 6722357 - INSTRUCTIONS
