BOLT 29G416 (5)
1 29G416
- 29G416 - BOLT
2 54K20002
- 54K20002 - O'RING 10
3 6587763
- 6587763 - BOOT
4 6589564
- 6589564 - RETAINER
5 6589565
- 6589565 - SEAL
- seal
6 7108251
- 7108251 - SPOOL
- LIFT
- Was 7101151
7 7108242
- 7108242 - SPOOL
- TILT
8 7300937
- 7300937 - SPOOL AUX
- auxiliary - Was 6588074
9 6592115
- 6592115 - SEAT
- load check
10 6592117
- 6592117 - SPRING
- LOAD CHECK
11 79K8
- 79K8 - O RING 10
12 6592116
- 6592116 - NUT
- load check
13 7219324
- 7219324 - VALVE
- RELIEF
- W/ O-rings - pressure to be set in field - Was 6686360
14 1K127
- 1K127 - O-RING 10
- Was 93K127
15 58K017
- 58K017 - O-RING 10
16 6665569
- 6665569 - RING
- BACK-UP
- back-up
17 25K20016
- 25K20016 - O RING 10
18 6665570
- 6665570 - CLYD RING
- glide
19 6683274
- 6683274 - SEAL
- SPOOL 10
- - spool - Was 6665846
20 6534630
- 6534630 - RESTRICTOR
- .134/.141
21 79K10
- 79K10 - O RING 10
22 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
23 6677106
- 6677106 - O-RING
- back-up washer not required
24 58K014
- 58K014 - O-RING 10
- back-up washer required
25 29G412
- 29G412 - BOLT
26 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- Was 6587633
27 7102652
- 7102652 - SCREW
- Was 30G000416B
28 6592109
- 6592109 - ADAPTER
29 6592100
- 6592100 - COLLAR
30 6587580
- 6587580 - SPRING
31 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
32 79K7
- 79K7 - O RING 10
- Was 75K-12
33 55K212
- 55K212 - O RING 10
34 6806561
- 6806561 - PLUG W/SEALS
- W/Ref. 33 & 48 - Hex Head
35 55K204
- 55K204 - O RING 10
36 6596332
- 6596332 - SPRING
37 6806007
- 6806007 - SPRING
- blue
38 6662848
- 6662848 - CAP
39 6803092
- 6803092 - BONNET
- .625" flange
40 6801167
- 6801167 - SPOOLPLUG
- plastic - 0.69" long
41 6595663
- 6595663 - BUSHING
42 6588781
- 6588781 - END CAP
43 6592720
- 6592720 - PLUG
- W/ Ref. 23-25
44 25K20012
- 25K20012 - O RING 10
45 58K124
- 58K124 - O RING 10
46 7108780
- 7108780 - SLEEVE
- Was 6595951
47 6816250
- 6816250 - KIT
- SEAL
- One Spool - Ref. 2
- 3
- 4
- 16
- 21 & 26 - Was 6803605
48 6632279
- 6632279 - KIT
- SEAL
- main relief - Ref. 17-20 - main relief
49 6809425
- 6809425 - SEAL KIT
- Ref. 13 & 23-25
50 6816253
- 6816253 - KIT
- SEAL
- complete - Ref. 2
- 4
- 13
- 16-21
- 23-26
- 34
- 36
- 42
- 45
- 46
- 55 & 56 - Was 6809448
