PLATE

PLATE

PLATE

1 3974924

  • 3974924 - PLATE

2 3974925

  • 3974925 - PLATE

3 3974926

  • 3974926 - BREATHER

4 6653822

  • 6653822 - SHIELD

5 6667426

  • 6667426 - BOLT

6 6652624

  • 6652624 - CONNECTOR

7 3974930

  • 3974930 - PIPE

8 6653823

  • 6653823 - CLAMP
  • PIPE

9 6655175

  • 6655175 - COVER VALVE

10 6598136

  • 6598136 - GASKET
  • COVER VALVE

11 3974923

  • 3974923 - NUT

12 3974095

  • 3974095 - GASKET
  • METAL

13 6685924

  • 6685924 - OIL FILL CAP

14 6684782

  • 6684782 - O-RING
