WASHER, 5 6534111 (4)

WASHER, 5 6534111 (4)

WASHER, 5 6534111 (4)

1 6534111

  • 6534111 - WASHER
  • 5

2 6534154

  • 6534154 - RING
  • RETAINER

3 6597572

  • 6597572 - BUMPER

4 7172745

  • 7172745 - BUSHING
  • WEAR
  • Use W/pin W/ 12 mm dia cross bolt retaining hole

5 7176031

  • 7176031 - LINK

6 7143009

  • 7143009 - PIN
  • PIVOT BOOM

7 7143562

  • 7143562 - O-RING
  • 69
  • 2 mm (2.73") ID

8 7176090

  • 7176090 - PIN
  • W/A

9 7180024

  • 7180024 - ARM
  • DIPPER W/A EXC
  • standard arm - Also Order Ref. 4
  • 7 (7143562 o-ring)
  • 12
  • 17
  • & 22

10 7176092

  • 7176092 - PIN
  • W/A

11 7167301

  • 7167301 - BUSHING
  • WEAR

12 7176033

  • 7176033 - LINK

13 10H25

  • 10H25 - FTG GREASE STRAIGHT

14 26GM10020

  • 26GM10020 - SCREW HEX THRDRLG

15 7180025

  • 7180025 - ARM
  • DIPPER W/A LONG EXC
  • long arm - Also Order Ref. 4
  • 7 (7143562 o-ring)
  • 12
  • 17
  • & 22

16 6652915

  • 6652915 - SEAL
  • OIL

17 43DM10

  • 43DM10 - NUT FLANGED HEX

18 7CM1090

  • 7CM1090 - BOLT
  • HEX SOCKET

19 6586391

  • 6586391 - RETAINER
  • weld-on

20 6669287

  • 6669287 - SEAL
