FRAME 6918216 (2)

FRAME 6918216 (2)

FRAME 6918216 (2)

1 6918216

  • 6918216 - FRAME

2 7213359

  • 7213359 - BEARING SWING ID70L80

3 01775.6

  • 01775.6 - Grease Nipple

4 70811.5

  • 70811.5 - Bush

5 6909439

  • 6909439 - BUSHING

6 70811.5

  • 70811.5 - Bush

7 7229363

  • 7229363 - GASKET
  • BULK

8 79123.6

  • 79123.6 - Plate

9 79129.3

  • 79129.3 - Seal

10 13415.5

  • 13415.5 - Washer

11 79124.4

  • 79124.4 - Nut

12 010338-02X

  • 010338-02X - SCREW

13 6909712

  • 6909712 - HYDRAULIC OPERATION

14 6908248

  • 6908248 - COVER

15 01719.4

  • 01719.4 - Washer

16 01604.8

  • 01604.8 - Screw

17 57702.3

  • 57702.3 - Plug

18 79288.7

  • 79288.7 - Rubber mounting

19 6916450

  • 6916450 - RIVET

20 6915265

  • 6915265 - SUPPORT LIGHT LH

21 1CM1035

  • 1CM1035 - BOLT

22 000350-21R

  • 000350-21R - WASHER

23 7252655

  • 7252655 - NUT LOCK

24 6915264

  • 6915264 - SUPPORT LIGHT RH

25 100432-51C

  • 100432-51C - MIRROR
  • SIDE REAR

26 7CM10100

  • 7CM10100 - SCREW HEX HD 10.9

27 7252655

  • 7252655 - NUT LOCK

28 7247000

  • 7247000 - PIN

29 7249740

  • 7249740 - PLATE

30 01610.5

  • 01610.5 - Screw

31 89517.7

  • 89517.7 - Washer

32 1CM1040

  • 1CM1040 - BOLT

33 6913019

  • 6913019 - ARM ABUTMENT

34 7252655

  • 7252655 - NUT LOCK

35 5JM40

  • 5JM40 - SNAPRING

36 7308913

  • 7308913 - WASHER FLAT

37 7245021

  • 7245021 - PIN CYLINDER

38 53925.4

  • 53925.4 - Screw

39 6915401

  • 6915401 - CONNECTING ROD

40 7245395

  • 7245395 - NUT LOCK

41 77192.3

  • 77192.3 - Bush
