KIT, CUP 6701918
1 6701918
- 6701918 - KIT
- CUP
- Ref. 2-5
2 6655759
- 6655759 - TOOTH
- TRENCHER CARBIDE
- RH
3 6655760
- 6655760 - TOOTH
- TRENCHER CARBIDE
- LH
4 17C616
- 17C616 - BOLT 5
5 85D6
- 85D6 - NUT PRETRQ HEX LOCK
6 6705531
- 6705531 - KIT
- CARBIDE 24-36
- Ref. 7-12 & 14-18
7 7193188
- 7193188 - HOLDER
- BIT
- RH - welded - 44
- 5 mm x 71
- 6 mm (1.75" x 2
- 82") base - W/O bit
8 6655757
- 6655757 - HOLDER
- BIT
- RH - cast - 20 mm x 75
- 7 mm (.79" x 2.98") base - W/O bit - not in kit
9 7193187
- 7193187 - HOLDER
- BIT
- LH - welded - 44
- 5 mm x 71
- 6 mm (1.75" x 2
- 82") base - W/O bit
10 6655756
- 6655756 - HOLDER
- BIT
- LH - cast - 20 mm x 75
- 7 mm (.79" x 2.98") base - W/O bit - not in kit
11 6655758
- 6655758 - HOLDER
- BIT
- inline - cast - 20 mm x 75
- 7 mm (.79" x 2.98") base - W/O bit - not in kit
12 7193189
- 7193189 - HOLDER
- BIT
- inline - welded - 44
- 5 mm x 71
- 6 mm (1.75" x 2
- 82") base - W/O bit
13 6655755
- 6655755 - BIT
- CARBIDE
- W/Ref. 11
14 6633840
- 6633840 - WASHER 5
15 35C640
- 35C640 - BOLT 10
- tooth mounted on inside
16 31C648
- 31C648 - BOLT
- tooth mounted on outside - Was 35C648
17 6557831
- 6557831 - WASHER CONTROLS
- Use W/carbide bits
18 83D6
- 83D6 - LKNUT HEX FLG GR8
- flange head - Use W/carbide bits - Was 97D6
19 6705530
- 6705530 - SPACER 10
- 22
- 86 mm (0.90") long - Use W/SS chain - tooth mounted on inside
20 6576369
- 6576369 - SPACER
- 35
- 3 mm (1.39") long - Use W/SS chain - tooth mounted on outside
21 6701878
- 6701878 - BUSHING
- 25
- 9 mm (1.02") long - Use W/DS chain - tooth mounted on inside
22 6701880
- 6701880 - BUSHING
- 38
- 6 mm (1.52") long - Use W/DS chain - tooth mounted on outside
