Комплектующие масляного насоса и регулятор
1 233283
- 233283 - Thrust Plate & Bearing Assembly
- Кол-во: 2
2 238119
- 238119 - Pump Driven Shaft Assembly
- Кол-во: 1
3 234641
- 234641 - Thrust Plate & Bearing Assembly
- Кол-во: 2
4 234640
- 234640 - Wave Spring
- Кол-во: 2
5 234643
- 234643 - Pump Shaft Seal
- Кол-во: 2
6 243731
- 243731 - Pump Drive Shaft Assembly
- Кол-во: 1
7 243725
- 243725 - Charging Pump Ass’v.
- Кол-во: 1
- Incl.Items 1 thru 6
- 10
8 91F12
- 91F12 - Pump Suction Adaptor O RING
- Кол-во: 1
9 243642
- 243642 - Pump Suction Adaptor Fitting
- Кол-во: 1
- Not Used On This Model
11 243641
- 243641 - Charging Pump Suction Tube Coupling
- Кол-во: 1
12 243640
- 243640 - Charging Pump Suction Tube Retainer
- Кол-во: 1
13 243639
- 243639 - Charging Pump Suction Tube Gasket
- Кол-во: 1
14 243638
- 243638 - Charging Pump Suction Tube Sleeve
- Кол-во: 1
15 243702
- 243702 - Lifting Eye & Suction Flange Plate
- Кол-во: 1
16 60K60124
- 60K60124 - Rear Cover Suction Flange O RING
- Кол-во: 1
17 60K40424
- 60K40424 - Regulator Valve Pilot O RING
- Кол-во: 1
18 244718
- 244718 - Spring Retainer Snap Ring
- Кол-во: 1
19 243974
- 243974 - Valve Spring Retainer Cup
- Кол-во: 1
20 247801
- 247801 - Valve Spring - Outer
- Кол-во: 1
21 247802
- 247802 - Valve Spring - Inner
- Кол-во: 1
22 243688
- 243688 - Regulator Valve Spool
- Кол-во: 1
23 60K40026
- 60K40026 - Clutch Pressure Supply O RING
- Кол-во: 1
25 1C824
- 1C824 - Valve to Conv. Hsg. Screw
- Кол-во: 2
26 24K3
- 24K3 - Regulator Valve Plug
- Кол-во: 1
27 24K3
- 24K3 - Regulator Valve Plug
- Кол-во: 1
28 247755
- 247755 - Pressure Regulator Valve Ass’y.
- Кол-во: 1
- Incl. Items 18 thru 22
- 26 thru 33
29 247752
- 247752 - Safety Valve Piston
- Кол-во: 1
30 243646
- 243646 - Safety Valve Piston Ring
- Кол-во: 1
31 243722
- 243722 - Piston Spring Retainer
- Кол-во: 1
32 247486
- 247486 - Spring Retainer Snap Ring
- Кол-во: 1
33 456294
- 456294 - Pump Shaft Oil Seal
- Кол-во: 1
34 238116
- 238116 - Valve Body to Purnp Gasket
- Кол-во: 1
36 1C620
- 1C620 - Valve to Purnp Screw
- Кол-во: 2
36 4E6
- 4E6 - Valve to Purnp Screw Lockwasher
- Кол-во: 2
37 4E6
- 4E6 - Valve to Purnp Screw Lockwasher
- Кол-во: 2
38 1C664
- 1C664 - Valve to Purnp Screw
- Кол-во: 2
39 1C820
- 1C820 - Lifting Eye & Suction Flange Mtg. Screw
- Кол-во: 4
39 4E8
- 4E8 - Lifting Eye & Suction Flange Mtg. Screw Lockwasher
- Кол-во: 4
40 4E8
- 4E8 - Valve to Conv. Hsg. Screw Lackwasher
- Кол-во: 2
41 243680
- 243680 - Regulator Valve & Charging Pump Ass’y.
- Кол-во: 1
- Incl. Items 7
- 28
- 34 thru 38
42 47K5
- 47K5 - Clutch Pressure Supply Plug
- Кол-во: 1
- Not Illustrated
