(SK200SR) - SHORT RADIUS EXCAVATOR BTW YB04-02301 - YB04-02550 (1/03-12/04)
/
MIRROR YY52C00003F1 (2)

MIRROR YY52C00003F1 (2)

MIRROR YY52C00003F1 (2)

1 YY52C00003F1

  • YY52C00003F1 - MIRROR

2 YY52C01007P1

  • YY52C01007P1 - STAY

3 YY52C01003P1

  • YY52C01003P1 - CLAMP

4 2456Z253

  • 2456Z253 - MIRROR

5 YY52C01006P1

  • YY52C01006P1 - SUPPORT

6 ZS18C08045

  • ZS18C08045 - SCREW
  • Hex
  • M8 x 45mm

7 ZW26X08000

  • ZW26X08000 - LOCK WASHER

8 ZN18C12010

  • ZN18C12010 - NUT

9 ZW16X12000

  • ZW16X12000 - WASHER

10 R16T0137D1

  • R16T0137D1 - WASHER

11 ZW16X08000

  • ZW16X08000 - WASHER
  • 8mm ID x 17mm OD x 1.6mm Thk

12 YT52C00008F3

  • YT52C00008F3 - MIRROR

13 YT52C00008F4

  • YT52C00008F4 - MIRROR

14 2456Z253

  • 2456Z253 - MIRROR

15 YY02C01004P1

  • YY02C01004P1 - STAY

16 ZN18C12010

  • ZN18C12010 - NUT

17 ZW16X12000

  • ZW16X12000 - WASHER

18 R16T0137D1

  • R16T0137D1 - WASHER

19 YY02C01001P1

  • YY02C01001P1 - PLATE

20 ZS18C10045

  • ZS18C10045 - SCREW
  • Hex
  • M10 x 45mm

21 ZW26X10000

  • ZW26X10000 - LOCK WASHER

22 ZW16H10000

  • ZW16H10000 - WASHER

23 YN02C01121P1

  • YN02C01121P1 - MIRROR

24 ZM46C05016

  • ZM46C05016 - BOLT
  • Phillip
  • M5 x 0.8 x 15mm

25 YT50C01077P1

  • YT50C01077P1 - BLOCK
