Механизм привода клапанов
1 4110000405161
- 4110000405161 - Hexagon bolt
- Кол-во: 12
- 90011350067
2 4110000405162
- 4110000405162 - Carrying arm
- Кол-во: 6
- 612600050028
3 4110000405163
- 4110000405163 - Valve rocker arm seat assembly
- Кол-во: 6
- 612600050027
4 4110000405164
- 4110000405164 - Intake valve rocker arm
- Кол-во: 6
- 612600050177
5 4110000405165
- 4110000405165 - Valve cap
- Кол-во: 12
- 61500050105
6 4110000405166
- 4110000405166 - Valve collet
- Кол-во: 24
- 61500050025
7 4110000405167
- 4110000405167 - Valve spring seat (upper)
- Кол-во: 12
- 61500050109
8 4110000405168
- 4110000405168 - Inner valve spring
- Кол-во: 12
- 61500050001
9 4110000405169
- 4110000405169 - Outer valve spring
- Кол-во: 12
- 61500050002
10 4110000405170
- 4110000405170 - Intake valve spring seat (lower)
- Кол-во: 6
- 614050017
11 4110000405171
- 4110000405171 - Intake valve
- Кол-во: 6
- 612600050073
12 4110000405172
- 4110000405172 - Push rod
- Кол-во: 12
- 612600050214
13 4110000405173
- 4110000405173 - Tappet
- Кол-во: 12
- 61500050032
14 4110000405174
- 4110000405174 - Camshaft assembly
- Кол-во: 1
- 612600050087
15 4110000405175
- 4110000405175 - Camshaft gear
- Кол-во: 1
- 61800050144
16 4110000405176
- 4110000405176 - Hexagon bolt
- Кол-во: 4
- 612600050145S
17 4110000405177
- 4110000405177 - Hexagon bolt
- Кол-во: 4
- 61560050059S
18 4110000405178
- 4110000405178 - Gasket
- Кол-во: 1
- 61560050045
19 4110000405179
- 4110000405179 - Shaft
- Кол-во: 1
- 61560050058
20 4110000405180
- 4110000405180 - Intermediate gear assembly
- Кол-во: 1
- 61800050098
21 4110000405181
- 4110000405181 - Hexagon bolt
- Кол-во: 2
- 90003802399S
22 4110000405182
- 4110000405182 - Camshaft thrust
- Кол-во: 1
- 614050133
23 4110000405183
- 4110000405183 - Intermediate gear shaft
- Кол-во: 1
- 61560050044
24 4110000405184
- 4110000405184 - Screw joint
- Кол-во: 1
- 612600050041
25 4110000405185
- 4110000405185 - Hollow bolt
- Кол-во: 1
- 612600050039
26 4110000405186
- 4110000405186 - Seal washer
- Кол-во: 12
- 612600050042
27 4110000405187
- 4110000405187 - EVB fuel inlet pipe assembly (long)
- Кол-во: 1
- 612600050161
28 4110000405188
- 4110000405188 - Fuel inlet pipe assembly (short)
- Кол-во: 5
- 612600050101
29 4110000405189
- 4110000405189 - Hollow bolt adapter
- Кол-во: 5
- 612600050040
30 4110000405190
- 4110000405190 - Exhaust valve
- Кол-во: 6
- 612600050025
31 4110000405191
- 4110000405191 - Exhaust valve spring seat (lower)
- Кол-во: 1
- 61500040014
32 4110000405192
- 4110000405192 - EVB Exhaust Rocker Arm Set
- Кол-во: 6
- 612600050179-EVB
33 4110000405193
- 4110000405193 - Ad justment bolt assembly
- Кол-во: 6
- 612600050038
34 4110000405194
- 4110000405194 - Valve adjusting nut
- Кол-во: 6
- 2130050065
