Система рабочая гидравлическая 11Y0639_000_01
9 10C0695
- 10C0695 - BLADE LIFT CYLINDER
- Кол-во: 2
10 30C0164
- 30C0164 - CONNECTOR
- Кол-во: 7
17 09C0203
- 09C0203 - CLAMP
- Кол-во: 4
32 07C7484
- 07C7484 - HOSE AS
- Кол-во: 1
33 07C7485
- 07C7485 - HOSE AS
- Кол-во: 1
34 82A1524
- 82A1524 - PAD
- Кол-во: 1
35 10C1066
- 10C1066 - STEERING CYLINDER
- Кол-во: 2
36 06C7536
- 06C7536 - HOSE AS
- Кол-во: 1
- 20591-24-08X2SN08 X1130V280° +RNL
37 06C7528
- 06C7528 - HOSE AS
- Кол-во: 1
- 20591-24-08X2SN08 X780V280° +RNL
38 02A0281
- 02A0281 - TEE
- Кол-во: 2
39 05C5637
- 05C5637 - HOSE AS
- Кол-во: 1
40 66C1495
- 66C1495 - HOSE AS
- Кол-во: 1
45 44C1791
- 44C1791 - CONTROL VALVE AS
- Кол-во: 1
46 31C0113
- 31C0113 - CONNECTOR
- Кол-во: 1
47 44C1633
- 44C1633 - HYDRAULIC LOCK
- Кол-во: 1
48 06C7533
- 06C7533 - HOSE AS
- Кол-во: 2
- 20541-24-08/20591 -24-08X2SN08X2400 V0° +RNL
49 06C9316
- 06C9316 - HOSE AS
- Кол-во: 1
50 10C0694
- 10C0694 - BLADE SIDESHIFT CYLINDER
- Кол-во: 1
51 10C0669
- 10C0669 - BLADE PITCH CYLINDER
- Кол-во: 1
52 31C0145
- 31C0145 - CONNECTOR
- Кол-во: 4
53 06C7535
- 06C7535 - HOSE AS
- Кол-во: 1
56 09C0795
- 09C0795 - CLAMP
- Кол-во: 1
57 37B0010
- 37B0010 - CABLE TIE
- Кол-во: 13
58 10C0663
- 10C0663 - FRONT WHEEL TILT CYLINDER
- Кол-во: 1
59 06C6762
- 06C6762 - HOSE AS
- Кол-во: 2
60 31C0084
- 31C0084 - ELBOW
- Кол-во: 2
61 66C0158
- 66C0158 - HOSE AS
- Кол-во: 1
62 66C0157
- 66C0157 - HOSE AS
- Кол-во: 1
65 06C7534
- 06C7534 - HOSE AS
- Кол-во: 1
66 66C0436
- 66C0436 - HOSE AS
- Кол-во: 1
67 37B0004
- 37B0004 - NYLON STRAP
- Кол-во: 16
68 66C0156
- 66C0156 - HOSE AS
- Кол-во: 4
69 66C2287
- 66C2287 - HOSE AS
- Кол-во: 2
70 66C2285
- 66C2285 - HOSE AS
- Кол-во: 2
71 10C0668
- 10C0668 - BLADE PITCH CYLINDER
- Кол-во: 1
72 66C2286
- 66C2286 - HOSE AS
- Кол-во: 2
73 06C7532
- 06C7532 - HOSE AS
- Кол-во: 1
74 09C1610
- 09C1610 - CLAMP
- Кол-во: 2
75 84A0341
- 84A0341 - GROMMET
- Кол-во: 2
76 66C7608
- 66C7608 - HOSE AS
- Кол-во: 1
77 07C4682
- 07C4682 - HOSE AS
- Кол-во: 1
78 07C4683
- 07C4683 - HOSE AS
- Кол-во: 1
79 32C0114
- 32C0114 - TEE
- Кол-во: 2
80 06C7530
- 06C7530 - HOSE AS
- Кол-во: 1
81 06C7529
- 06C7529 - HOSE AS
- Кол-во: 1
82 07C4684
- 07C4684 - HOSE AS
- Кол-во: 1
83 44C1793
- 44C1793 - SPACER CONNECTOR
- Кол-во: 1
84 66C7765
- 66C7765 - HOSE AS
- Кол-во: 1
85 66C7766
- 66C7766 - HOSE AS
- Кол-во: 1
86 44C0085
- 44C0085 - JOINT
- Кол-во: 1
87 44C1788
- 44C1788 - PUMP AS
- Кол-во: 1
