New Holland Construction
/
(FD20) - CRAWLER DOZER
/
LOCKING PLATE 8299995 (1)

LOCKING PLATE 8299995 (1)

LOCKING PLATE 8299995 (1)

1 8299995

  • 8299995 - LOCKING PLATE

2 10571971

  • 10571971 - LOCK WASHER

3 11112431

  • 11112431 - SCREW
  • Hex
  • M12 x 30mm
  • Cl 10.9
  • Full Thd

4 11195071

  • 11195071 - WASHER

5 13407211

  • 13407211 - LUBE NIPPLE
  • M10 x 1

6 14164470

  • 14164470 - LOCK PIN
  • M4 x 32
  • Slotted

7 16164037

  • 16164037 - BOLT
  • Hex
  • M30 x 2 x 70mm
  • Cl 10.9
  • Full Thd

8 79024181

  • 79024181 - PIN

9 79024860

  • 79024860 - SUPPORT

10 79024875

  • 79024875 - PIN

11 79024883

  • 79024883 - BLOCK

12 79024884

  • 79024884 - PIN

13 79027050

  • 79027050 - LINK
