New Holland Construction
/
(LS190.B) - SKID STEER LOADER - NA
/
HYDRAULIC MOTOR,470CC 87035341 (3)

HYDRAULIC MOTOR,470CC 87035341 (3)

HYDRAULIC MOTOR,470CC 87035341 (3)

1 87035341

  • 87035341 - HYDRAULIC MOTOR
  • 470CC
  • One Speed
  • Incl. Figure 06-08 - 06-10

2 87035341R

  • 87035341R - REMAN-HYD MOTOR
  • Reman for New PN 87035341

3 87035341C

  • 87035341C - CORE-MOTOR HYDRAULIC
  • Return Number

4 87039359

  • 87039359 - BEARING ASSY
  • Shaft And Bearing

5 87042941

  • 87042941 - CASE
  • Front

6 87042908

  • 87042908 - CAM
  • 680/470

7 87042953

  • 87042953 - CASE
  • Rear

8 861-14080

  • 861-14080 - HEX SOC SCREW
  • M14 x 80mm
  • Cl 12.9

9 87042912

  • 87042912 - SPRING

10 86512142

  • 86512142 - HEX SOC SCREW
  • M12 x 30mm
  • Cl 12.9
  • Full Thd

11 87042921

  • 87042921 - HOUSING
  • Brake

12 87042926

  • 87042926 - SPRING
  • Disc

13 87042923

  • 87042923 - COVER
  • End

14 87042904

  • 87042904 - BALL BEARING
  • 70 mm ID x 110 mm OD x 25 mm
  • 70 x 110 x 25

15 87042905

  • 87042905 - BALL BEARING
  • 50mm ID x 110mm OD x 29.25mm W
  • 50 x 110 x 29.25

16 87042903

  • 87042903 - KIT
  • Washer

17 87042906

  • 87042906 - RING
  • Split Ring

18 NSS

  • NSS - NOT SOLD SEPARAT

19 NSS

  • NSS - NOT SOLD SEPARAT

20 861-8040

  • 861-8040 - HEX SOC SCREW
  • M8 x 40mm
  • Cl 12.9

21 87042954

  • 87042954 - RING
  • Distributor

22 87042911

  • 87042911 - PIN
  • Stop

23 87042927

  • 87042927 - PIN
  • 12 x 25

24 87042925

  • 87042925 - CLIP
  • 87 ID

25 87042922

  • 87042922 - PISTON
  • Brake

26 86512134

  • 86512134 - HEX SOC SCREW
  • M6 x 16mm
  • Cl 12.9

27 218-5156

  • 218-5156 - PLUG
  • Hex Hd
  • 3/4"-16 ORB
  • Incl. 25

28 237-6008

  • 237-6008 - O-RING
  • 0.087" Thk x 0.644" ID
  • -908
  • Cl 6
  • 90 Duro
