New Holland Construction
/
(RG200) - MOTOR GRADER (4/99-)
/
ELECTRIC CABLE 75249881

ELECTRIC CABLE 75249881

ELECTRIC CABLE 75249881

1 75249881

  • 75249881 - ELECTRIC CABLE

2 75253793

  • 75253793 - FRONT LAMP

3 75251230

  • 75251230 - LAMP
  • 24V
  • 21W
  • Amber

4 75252471

  • 75252471 - COVER

5 75251229

  • 75251229 - LAMP

6 12644421

  • 12644421 - WASHER
  • 6.15mm ID x 15mm OD x 1mm Thk

7 70928182

  • 70928182 - SCREW

8 10902131

  • 10902131 - SCREW
  • Hex
  • M6 x 14mm
  • Cl 10.9
  • Full Thd

9 75252472

  • 75252472 - SUPPORT

10 75252474

  • 75252474 - SUPPORT

11 16043431

  • 16043431 - SCREW
  • Hex
  • M8 x 1.25 x 20mm
  • Cl 10.9
  • Full Thd

12 14496531

  • 14496531 - WASHER
  • 8.4mm ID x 17mm OD x 1.6mm Thk
