Система электрическая поворотной платформы 13798154
1 60224106
- 60224106 - camera
- Кол-во: 2
- CM10Z TS-IR100
2 11251180
- 11251180 - Hoist lighting assembly
- Кол-во: 2
3 11694579
- 11694579 - Junction box mounting plate
- Кол-во: 2
4 A210210000008
- A210210000008 - screw
- Кол-во: 40
5 A210405000006
- A210405000006 - washer
- Кол-во: 40
6 A210401000016
- A210401000016 - washer
- Кол-во: 40
7 13798732
- 13798732 - Installation of junction box at the tail of the turntable
- Кол-во: 1
8 A210204000121
- A210204000121 - screw
- Кол-во: 8
- M5x40GB70.1
9 A210401000015
- A210401000015 - washer
- Кол-во: 8
10 A210405000005
- A210405000005 - washer
- Кол-во: 8
11 11694580
- 11694580 - Contactor box mounting plate
- Кол-во: 1
12 13801249
- 13801249 - Contactor junction box installation
- Кол-во: 1
13 13798477
- 13798477 - Turntable distribution box 7 installation
- Кол-во: 1
14 13798476
- 13798476 - Turntable distribution box 6 installation
- Кол-во: 1
15 12701056
- 12701056 - Heavy-duty rain cover
- Кол-во: 12
16 A210210000018
- A210210000018 - bolt
- Кол-во: 21
17 A210307000014
- A210307000014 - nut
- Кол-во: 21
- M4GB6170
18 A210405000004
- A210405000004 - washer
- Кол-во: 21
19 A210401000013
- A210401000013 - washer
- Кол-во: 21
20 13798475
- 13798475 - Turntable distribution box 5 installation
- Кол-во: 1
21 A810201206238
- A810201206238 - Pressure sensor
- Кол-во: 1
- 10MPa-24V-I-G1/4-M12
22 A810201206126
- A810201206126 - Pressure sensor
- Кол-во: 7
- 60MPa-24V-I-G1/4-M12 Sany
23 13798474
- 13798474 - Turntable distribution box 4 installation
- Кол-во: 1
24 13798473
- 13798473 - Turntable distribution box 3 installation
- Кол-во: 1
25 13798731
- 13798731 - Installation of junction box at the front of the turntable
- Кол-во: 1
26 60117974
- 60117974 - Limit switch
- Кол-во: 1
- GY-S-1NO+1NC-750
27 11326014
- 11326014 - Manual speaker installation assembly
- Кол-во: 1
28 13179736
- 13179736 - Rotary reset detection assembly
- Кол-во: 1
29 11694581
- 11694581 - Junction box mounting plate
- Кол-во: 1
30 11285151
- 11285151 - Inclination sensor assembly
- Кол-во: 1
31 12098118
- 12098118 - 16-core heavy-duty closed base assembly
- Кол-во: 2
32 13798471
- 13798471 - Turntable distribution box 1 installation
- Кол-во: 1
33 11261671
- 11261671 - 6-core heavy-duty closed base assembly
- Кол-во: 2
34 12599404
- 12599404 - Platform camera and lighting installation
- Кол-во: 1
35 11300912
- 11300912 - Battery installation
- Кол-во: 2
36 60012778
- 60012778 - Power cord
- Кол-во: 1
- Q/SY015029 3800
37 13798472
- 13798472 - Turntable distribution box 2 installation
- Кол-во: 1
38 A810201206239
- A810201206239 - Temperature transmitter
- Кол-во: 1
- SYTT-ZI(-30)90lV-M121-G1/2
39 12649288
- 12649288 - Speaker assembly
- Кол-во: 1
40 10849303
- 10849303 - Speaker cover
- Кол-во: 1
- tb405.000.00
41 21028139
- 21028139 - Oil level sensor installation
- Кол-во: 1
42 11326017
- 11326017 - Adapter cable assembly
- Кол-во: 1
43 11583836
- 11583836 - 24-core heavy-duty plug adapter cable assembly
- Кол-во: 1
44 11326001
- 11326001 - Adapter cable assembly
- Кол-во: 2
45 12263033
- 12263033 - Adapter cable assembly
- Кол-во: 1
46 12263036
- 12263036 - Adapter cable assembly
- Кол-во: 1
47 11326011
- 11326011 - Adapter cable assembly
- Кол-во: 1
48 12194568
- 12194568 - Adapter cable assembly
- Кол-во: 1
49 11583837
- 11583837 - Core ITT plug adapter cable assembly
- Кол-во: 2
50 11583838
- 11583838 - Core ITT plug adapter cable assembly
- Кол-во: 1
- 32
51 60224111
- 60224111 - Video cable
- Кол-во: 2
- PL20HK(TS-MC20) 20m
52 60224110
- 60224110 - Video cable
- Кол-во: 2
- PL10HK(TS-MC10) 10m
53 60224109
- 60224109 - Video cable
- Кол-во: 5
- PL5HK(TS-MC5) 5m
54 11416866
- 11416866 - Four-wire waterproof plug assembly
- Кол-во: 8
- Deutsch
55 13917972
- 13917972 - Electrical installation of fuel pump
- Кол-во: 1
