Узел вентилятора S00005771
1 G1610311
- G1610311 - ADAPTER
- FAN
- Кол-во: 1
2 B00000509
- B00000509 - HEXAGON HEAD BOLT
- Кол-во: 6
- GB/T5783-M10*30
3 B00001237
- B00001237 - SINGLE COIL SPRING LOCK WASHERS
- NORMAL TYPE
- Кол-во: 6
- GB/T93-10
4 G1610211
- G1610211 - PULLEY
- FAN
- Кол-во: 1
5 G1611002
- G1611002 - INTERNAL SPACER
- FAN
- Кол-во: 1
6 B00000245
- B00000245 - ROLLING BEARING
- Кол-во: 2
- GB/T276-6308-Z
7 B00000772
- B00000772 - HEXAGON NUTS
- STYLE 1
- Кол-во: 4
- GB/T6170-M12-Y
8 B00001239
- B00001239 - SINGLE COIL SPRING LOCK WASHERS
- NORMAL TYPE
- Кол-во: 5
- GB/T93-12
9 B00001724
- B00001724 - HEXAGONAL HEAD SCREW PLUG
- Кол-во: 1
- Q/SC587.1-M10*1
10 G1600103
- G1600103 - BASE ASSY
- FAN BEARING
- Кол-во: 1
10 G1610106
- G1610106 - BASE
- FAN BEARING
- Кол-во: 1
10 B00001124
- B00001124 - STUD
- Кол-во: 4
- GB/T899-GM12-M12*35-8.8-Y
11 B00001479
- B00001479 - GREASE FILLING JET
- Кол-во: 1
- JB/T7940.1-M10*1
12 G1611101
- G1611101 - SHAFT
- FAN
- Кол-во: 1
13 B00001353
- B00001353 - AUTOMOTIVE V-BELT
- Кол-во: 2
- GB12732-AV17*1600
14 B00001803
- B00001803 - BIGGER BLACK WASHERS
- Кол-во: 1
- Q/SC597-12*50
15 B00000538
- B00000538 - HEXAGON HEAD BOLT
- Кол-во: 1
- GB/T5783-M12*25
