Компоненты блока цилиндров
1 B00004189
- B00004189 - SMALL HEX HEAD BOLT WITH WIRE HOLE ON HEAD
- Кол-во: 2
- Q/SC611.3-M8*28
2 B00001998
- B00001998 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 2
- Q/SC622-M10*20-ZN.D
3 B00004895
- B00004895 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 2
- GB/T16674.1-M8*12-10.9-F
4 W02E11901
- W02E11901 - OIL BAFFLE
- Кол-во: 1
5 W02E11501
- W02E11501 - SPACER
- Кол-во: 2
6 W02E10101
- W02E10101 - GASKET
- CAMSHAFT HOUSING COVER
- Кол-во: 1
7 S00023878
- S00023878 - END PLANT
- VENT-CRANKCASE
- Кол-во: 1
8 S00023269
- S00023269 - GASKET
- Кол-во: 1
9 B00002056
- B00002056 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 2
- Q/SC622-M12*35-ZN.D
10 S00023268
- S00023268 - MIST INLET PIPE
- CRANKCASE VENT FILTER
- Кол-во: 1
13 B00002050
- B00002050 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 18
- Q/SC622-M12*30
14 B00001571
- B00001571 - CLAMP
- Кол-во: 2
- Q/SC1302-27~51
15 B00002388
- B00002388 - RUBBER HOSE
- WATER
- Кол-во: 1
- Q/SC646-38*80
16 S00014981
- S00014981 - CRANKCASE VENT FILTER ASSY
- Кол-во: 1
18 B00001565
- B00001565 - CLAMP
- Кол-во: 4
- Q/SC1302-18~32
19 D4211530
- D4211530 - HOSE PIPE
- Кол-во: 2
20 S00021508
- S00021508 - OIL RETURN PIPE
- CRANKCASE VENT FILTER
- Кол-во: 1
21 B00002097
- B00002097 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 1
- Q/SC622-M16*35
22 W02F10901
- W02F10901 - GASKET
- CAMSHAFT HOUSING COVER
- Кол-во: 5
23 S00023877
- S00023877 - END PLANT
- VENT-CRANKCASE
- Кол-во: 2
24 W02F10601
- W02F10601 - COVER
- CAMSHAFT HOUSING
- Кол-во: 3
25 B00001278
- B00001278 - PLAIN WASHER
- Кол-во: 7
- GB/T97.1-12-200HV-Y
26 B00004162
- B00004162 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 7
- GB/T16674.1-M12*40
27 B00002049
- B00002049 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 16
- Q/SC622-M12*25-ZN.D
28 B00002054
- B00002054 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 3
- Q/SC622-M12*35
29 W02F11101
- W02F11101 - GASKET
- CYLINDER BLOCK SIDE COVER
- Кол-во: 6
30 S00013190
- S00013190 - OIL FILLER FLANGE
- Кол-во: 1
31 B00002000
- B00002000 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 48
- Q/SC622-M10*25-ZN.D
32 D1231401
- D1231401 - O-RING
- Кол-во: 1
33 S00014680
- S00014680 - PIPE ELBOW
- OIL FILLER
- Кол-во: 1
34 S00018399
- S00018399 - COVER ASSY
- OIL FILLER
- Кол-во: 1
35 B00002134
- B00002134 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 4
- Q/SC622-M8*20
36 W02F10801
- W02F10801 - SIDE COVER PLATE
- CYLINDER BLOCK
- Кол-во: 5
