Система турбонагнетателя
0 S00012650
- S00012650 - HEAT SHIELD
- TURBOCHARGER
- Кол-во: 1
1 B00002178
- B00002178 - BOLT
- Кол-во: 1
- Q/SC642.1-01-M12*1.25
2 S00011472
- S00011472 - TURBOCHARGER OIL INLET PIPE
- Кол-во: 1
3 B00001818
- B00001818 - COPPER WASHER
- Кол-во: 2
- Q/SC598-12*16
4 S00003939
- S00003939 - CONNECTOR
- Кол-во: 1
5 S00005682
- S00005682 - O-RING
- Кол-во: 1
6 D1310850
- D1310850 - TURBOCHARGER SELF-LOCKING NUT
- Кол-во: 4
7 S00003525
- S00003525 - STUD
- Кол-во: 4
8 S00014383
- S00014383 - TURBOCHARGER
- Кол-во: 1
9 D1310352
- D1310352 - GASKET
- OUTLET-TURBINE
- Кол-во: 1
10 S00003835
- S00003835 - GASKET
- INLET-TURBINE
- Кол-во: 1
11 S00011473
- S00011473 - TURBOCHARGER OIL RETURN PIPE
- Кол-во: 1
12 S00003929
- S00003929 - TURBOCHARGER OIL RETURN TUBE GASKET
- Кол-во: 1
13 B00004893
- B00004893 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 2
- GB/T16674.1-M6*20-10.9-F
14 D02A17180
- D02A17180 - O-RING
- Кол-во: 2
15 S00000146
- S00000146 - EXPANSION CONNECTOR
- Кол-во: 1
16 B00002003
- B00002003 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 4
- Q/SC622-M10*30-ZN.D
17 S00012192
- S00012192 - EXHAUST PIPE ELBOW
- Кол-во: 1
18 B00001138
- B00001138 - STUD
- Кол-во: 5
- GB/T899-GM8-M8*30-8.8-Y
19 B00000793
- B00000793 - HEXAGON NUT (TYPE 1)
- Кол-во: 5
- GB/T6170-M8-Y
20 S00012191
- S00012191 - BRACKET
- EXHAUST PIPE ELBOW
- Кол-во: 1
21 B00002000
- B00002000 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 2
- Q/SC622-M10*25-ZN.D
22 S00011235
- S00011235 - CLAMP
- Кол-во: 2
23 B00002110
- B00002110 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 1
- Q/SC622-M6*10
24 B00000790
- B00000790 - HEXAGON NUT (TYPE 1)
- Кол-во: 1
- GB/T6170-M6-Y
25 A745DC13001
- A745DC13001 - GASKET
- MUFFLER
- Кол-во: 1
