Трубопровод топливный S00011084+01
1 G2600103A
- G2600103A - HIGH PRESSURE FUEL TUBE ASSY (NO.1 CYLINDER)
- Кол-во: 1
2 G2600203A
- G2600203A - HIGH PRESSURE FUEL TUBE ASSY (NO.2 CYLINDER)
- Кол-во: 1
3 G2600303A
- G2600303A - HIGH PRESSURE FUEL TUBE ASSY (NO.3 CYLINDER)
- Кол-во: 1
4 G2600403A
- G2600403A - HIGH PRESSURE FUEL TUBE ASSY (NO.4 CYLINDER)
- Кол-во: 1
5 G2600503A
- G2600503A - HIGH PRESSURE FUEL TUBE ASSY (NO.5 CYLINDER)
- Кол-во: 1
6 761G26063A
- 761G26063A - RETURN TUBE
- Кол-во: 1
7 B00002232
- B00002232 - BASE BANJO BOLT
- Кол-во: 6
- Q/SC642.3-1-M8*1*2
8 B00001555
- B00001555 - COMPOSITE HARD SEAL GASKET
- Кол-во: 12
- Q/SC1294-8
9 B00002118
- B00002118 - HEX HEAD BOLT
- Кол-во: 12
- Q/SC622-M6*20
10 A762ZA26004A
- A762ZA26004A - CLAMP
- Кол-во: 6
11 A762ZA26003A
- A762ZA26003A - CLAMP CUSHION
- Кол-во: 12
12 A762ZA26010A
- A762ZA26010A - FUEL INLET TUBE BRACKET ASSY
- Кол-во: 6
13 G2600603A
- G2600603A - HIGH PRESSURE FUEL TUBE ASSY (NO.6 CYLINDER)
- Кол-во: 1
14 G2611501A
- G2611501A - CLAMP
- Кол-во: 1
15 G2611701A
- G2611701A - CLAMP
- Кол-во: 11
16 B00002104
- B00002104 - HEX HEAD BOLT
- Кол-во: 8
- Q/SC622-M5*16
17 B00000839
- B00000839 - HEX FLANGE-FACE NUT
- Кол-во: 8
- GB/T6177-M5-8-Y
18 B00002132
- B00002132 - HEX HEAD BOLT
- Кол-во: 1
- Q/SC622-M8*16
19 77126014A
- 77126014A - LOW PRESSURE FUEL TUBE
- Кол-во: 1
20 77126180A
- 77126180A - FUEL INLET TUBE ASSY (WELDED)
- Кол-во: 1
21 763G26001AA
- 763G26001AA - HOSE
- Кол-во: 1
22 G2610401A
- G2610401A - CLAMP
- Кол-во: 1
23 B00001999
- B00001999 - HEX HEAD BOLT
- Кол-во: 1
- Q/SC622-M10*25
24 G2611401A
- G2611401A - CLAMP
- Кол-во: 1
25 77126015A
- 77126015A - LOW PRESSURE FUEL TUBE
- Кол-во: 1
26 G2600701A
- G2600701A - CLAMP CUSHION ASSY (WELDED)
- Кол-во: 2
27 G2611601A
- G2611601A - CLAMP
- Кол-во: 2
28 765KB02002A
- 765KB02002A - GASKET
- Кол-во: 2
