Система выхлопная C08AZ-08AZ016
1 C08ALM08AL009
- C08ALM08AL009 - DEFAULT
- Кол-во: 1
2 B00002003
- B00002003 - HEXAGON BOLTS
- Кол-во: 1
- Q/SC622-M10*30-ZN.D
3 B00000834
- B00000834 - NUT
- Кол-во: 11
- GB/T6177-M10-Zn.D
4 B00002015
- B00002015 - HEXAGON BOLTS
- Кол-во: 2
- Q/SC622-M10*50-ZN.D
5 C08AB08AB015
- C08AB08AB015 - EXHAUST PIPE ASSY (WELDED)
- Кол-во: 1
5 C08AL08AL015
- C08AL08AL015 - EXHAUST MANIFOLD
- Кол-во: 1
5 C08AL08AL021
- C08AL08AL021 - ADAPTER
- EXHAUST PIPE
- Кол-во: 1
5 B00000398
- B00000398 - HEXAGON HEAD BOLTS
- Кол-во: 1
- GB/T5782-M10*50-ZN.D
5 B00001276
- B00001276 - PLAIN WASHER
- Кол-во: 2
- GB/T97.1-10-200HV-ZN.D
5 B00000769
- B00000769 - NUT
- Кол-во: 1
- GB/T6170-M10-ZN.D
6 C08ALM2P7806
- C08ALM2P7806 - CLAMP
- Кол-во: 1
7 C08ALM8S6783
- C08ALM8S6783 - CLAMP
- Кол-во: 1
8 C08AB08AB016
- C08AB08AB016 - MUFFLER ASSY
- Кол-во: 1
9 C08ALM7N2450
- C08ALM7N2450 - FIXING CLAMP
- MUFFLER
- Кол-во: 1
10 B00002018
- B00002018 - HEXAGON HEAD BOLTS
- Кол-во: 2
- Q/SC622-M10*55-ZN.D
11 C08AB4W1667
- C08AB4W1667 - BRACKET ASSY (WELDED)
- MUFFLER
- Кол-во: 1
12 B00000837
- B00000837 - NUT
- Кол-во: 4
- GB/T6177-M12-Zn.D
13 C08ALM8S6783
- C08ALM8S6783 - CLAMP
- Кол-во: 1
13 B00002064
- B00002064 - HEXAGON HEAD BOLTS
- Кол-во: 4
- Q/SC622-M12*50-10.9-ZN.D
14 B00002012
- B00002012 - HEXAGON HEAD BOLTS
- Кол-во: 4
- Q/SC622-M10*45-ZN.D
15 C08ABM08AB009A
- C08ABM08AB009A - SUPPORT AS.
- Кол-во: 1
16 B00002006
- B00002006 - HEXAGON BOLTS
- Кол-во: 2
- Q/SC622-M10*35-ZN.D
