Насос масляный с комплектующими C15AZ-2P1784+A
0 C15AB6N2642A
- C15AB6N2642A - PUMP GP-ENGINE OIL (TWO SECTION GEAR)
- Кол-во: 1
- *1: Pump GP.-Engine Oil (Two Section Gear) 6N2642 includes parts of Ref.No.**8
- **9
- **10
- **11
- **12 **8: Pump GP.-Engine Oil includes parts of Ref.No. ***13
- ***14
- ***15
- ***16
- ***17
- ***18
- ***19
- ***20
- ***21
- ***22
- ***23
- ***24
- ***36
- ***37 ***13: Body As.-Scavenge Pump includes parts of Ref.No.(25)
- (26) ***14: Body As.-Oil Pump includes parts of Ref.No.(26)
- (27)*(29)
- (34)
- (35)
- (38) ***15: Drive Shaft includes parts of Ref.No.(30)
- (31) ***16: Driven Shaft includes parts of Ref.No.(31)
- (32) *(29): Shaft As.-Oil Pump Idler Gear includes parts of Ref.No.(28)
- (33)
0 U311A0S1590A
- U311A0S1590A - BOLT
- Кол-во: 3
0 C15AB4W2448A
- C15AB4W2448A - ENGINE OIL PUMP AS.
- Кол-во: 1
0 C15AL7W0507A
- C15AL7W0507A - GEAR-OIL PUMP DRIVE
- Кол-во: 1
0 U351A8M5599A
- U351A8M5599A - KEY-WOODRUFF-10
- Кол-во: 1
0 U382A1P7346A
- U382A1P7346A - WASHER-HARD
- Кол-во: 1
0 C15AB4W2321A
- C15AB4W2321A - BODY ASSEMBLY-SCAVENGE PUMP
- Кол-во: 1
0 C15AB4W2322A
- C15AB4W2322A - BODY AS．-OIL PUMP
- Кол-во: 1
0 C15AB2P6245A
- C15AB2P6245A - DRIVE SHAFT AS.
- Кол-во: 1
0 C15AB8S0493A
- C15AB8S0493A - SHAFT ASSEMBLY-OIL PUMP
- Кол-во: 1
0 C15AL2P2546A
- C15AL2P2546A - GEAR-OIL PUMP(GEAR-SCAVENGE PUMP)
- Кол-во: 1
0 C15AL2P1781A
- C15AL2P1781A - SPACER-OIL PUM
- Кол-во: 1
0 U351A1B8709A
- U351A1B8709A - KEY-WOODRUFF-10
- Кол-во: 1
0 B00000412
- B00000412 - BOLT GB/T5782-M10*90
- Кол-во: 3
0 C15AB4N8385A
- C15AB4N8385A - PRESSURE RELIEF VALVE AS.
- Кол-во: 1
0 C15AL4N3732A
- C15AL4N3732A - COVER-OIL PUMP BYPASS VALVE
- Кол-во: 1
0 B00000485
- B00000485 - BOLT GB/T5782-M8*50
- Кол-во: 1
0 B00001299
- B00001299 - WASHER-HARD GB/T97.1-8-200HV-Y
- Кол-во: 1
0 C15AL4N4054A
- C15AL4N4054A - BODY-SCAVENGE PUMP
- Кол-во: 1
0 C15AL8S6511A
- C15AL8S6511A - BEARING-SLEEVE
- Кол-во: 4
0 C15AL8N8635A
- C15AL8N8635A - BODY-OIL PUMP
- Кол-во: 1
0 B00000273
- B00000273 - STEEL BALL GB/T308-10
- Кол-во: 1
0 C15AB2P1170A
- C15AB2P1170A - SHAFT ASSEMBLY-OIL PUMP IDLER GEAR
- Кол-во: 1
0 C15AL2P0691A
- C15AL2P0691A - DRIVE SHAFT
- Кол-во: 1
0 C15AL2P2545A
- C15AL2P2545A - GEAR-OIL PUMP
- Кол-во: 2
0 C15AL8S0490A
- C15AL8S0490A - SHAFT-OIL PUMP
- Кол-во: 1
0 C15AL2P1169A
- C15AL2P1169A - SHAFT-OIL PUMP IDLER GEAR
- Кол-во: 1
0 B00000284
- B00000284 - STEEL BALL GB/T308-8
- Кол-во: 1
0 U362A1F1006A
- U362A1F1006A - DOWEL
- Кол-во: 1
0 B00001275
- B00001275 - WASHER GB/T97.1-10-200HV-Y
- Кол-во: 3
0 B00001237
- B00001237 - SPRING WASHER GB/T93-10
- Кол-во: 3
0 C15AL15AL001A
- C15AL15AL001A - RETAINER
- Кол-во: 2
2 C15AL4N5353A
- C15AL4N5353A - ELBOW-SCAVENGE LINE
- Кол-во: 1
3 C15AL2P8746B
- C15AL2P8746B - GASKET
- Кол-во: 1
5 U311A0S1619A
- U311A0S1619A - BOLT
- Кол-во: 1
6 U311A3B1915A
- U311A3B1915A - BOLT
- Кол-во: 2
7 U382A5M2894A
- U382A5M2894A - WASHER
- Кол-во: 4
11 U311A0S1590A
- U311A0S1590A - BOLT
- Кол-во: 1
