Генератор, шкивы, ремни и вентилятор
1 S00011762
- S00011762 - FAN ASSY
- Кол-во: 1
2 B00002047
- B00002047 - HEXAGON NUTS WITH FLANGE
- Кол-во: 4
- Q/SC622-M12*25
3 B00002050
- B00002050 - STUD
- Кол-во: 4
- Q/SC622-M12*30
4 S00013385
- S00013385 - SPACER
- FAN
- Кол-во: 1
6 B00000833
- B00000833 - HEXAGON NUTS WITH FLANGE
- Кол-во: 4
- GB/T6177-M10-Y
7 B00001150
- B00001150 - STUD
- Кол-во: 4
- GB/T899-M10*60-8.8-Y
8 S00004603
- S00004603 - FAN BEARING HOUSING
- Кол-во: 1
9 B00004630
- B00004630 - SIX ANGLE BOLT FLANGE
- Кол-во: 2
- GB/T16674.1-M10*80-10.9
10 S00001661
- S00001661 - TENSIONER ASSY
- Кол-во: 2
11 B00004373
- B00004373 - SIX ANGLE BOLT FLANGE
- Кол-во: 3
- GB/T16674.1-M8*50
12 S00006515
- S00006515 - BRACKET
- TENSIONER
- Кол-во: 1
13 B00004163
- B00004163 - SIX ANGLE BOLT FLANGE
- Кол-во: 7
- GB/T16674.1-M8*35
14 S00001908
- S00001908 - PULLEY
- CRANKSHAFT
- Кол-во: 1
15 S00004644
- S00004644 - BELT
- FAN
- Кол-во: 1
16 S00001981
- S00001981 - IDLER ASSY
- Кол-во: 1
18 S00010721
- S00010721 - BELT
- FAN
- Кол-во: 1
20 S00001894
- S00001894 - CRANKSHAFT DAMPER BOLT
- Кол-во: 7
21 S00001702
- S00001702 - CRANKSHAFT DAMPER ASSY
- Кол-во: 1
22 S00001972
- S00001972 - CRANKSHAFT SEAL
- FRONT
- Кол-во: 1
23 S00013782
- S00013782 - ALTERNATOR BRACKET
- Кол-во: 1
24 B00005031
- B00005031 - SIX ANGLE BOLT FLANGE
- Кол-во: 2
- GB/T16674.1-M10*45-10.9-ZN.D
25 S00001851
- S00001851 - ALTERNATOR BRACKET SPACER
- Кол-во: 1
26 S00016306
- S00016306 - ALTERNATOR GROUP
- Кол-во: 1
27 B00005049
- B00005049 - SIX ANGLE BOLT FLANGE
- Кол-во: 1
- GB/T16674.1-M10*90-10.9-ZN.D
28 B00001998
- B00001998 - SIX ANGLE BOLT FLANGE
- Кол-во: 2
- Q/SC622-M10*20-ZN.D
29 B00005036
- B00005036 - SIX ANGLE BOLT FLANGE
- Кол-во: 1
- GB/T16674.1-M10*30-10.9-ZN.D
30 S00006571
- S00006571 - ALTERNATOR BRACE ASSY
- Кол-во: 1
31 S00012326
- S00012326 - FRONT ENGINE SUPPORT
- Кол-во: 2
32 B00002082
- B00002082 - SIX ANGLE BOLT FLANGE
- Кол-во: 8
- Q/SC622-M14*30
