Блок цилиндров с комплектующими S00017107
1 763CA02024
- 763CA02024 - O-RING
- Кол-во: 1
2 B00000297
- B00000297 - O-RING
- Кол-во: 2
- GB/T3452.1-16*3.55
3 B00004832
- B00004832 - HEX HEAD BOLT (FLANGED)
- Кол-во: 2
- GB/T16674.2-M14*1.5*50
4 B00000952
- B00000952 - LIFTING SCREW
- Кол-во: 2
- GB/T825-M16-Y
5 B00002132
- B00002132 - HEX HEAD BOLT (FLANGED)
- Кол-во: 6
- Q/SC622-M8*16
6 763G02013
- 763G02013 - POINTER
- Кол-во: 1
7 G0217701
- G0217701 - COVER BOARD
- Кол-во: 1
8 B00002111
- B00002111 - HEX HEAD BOLT (FLANGED)
- Кол-во: 1
- Q/SC622-M6*12
9 B00001552
- B00001552 - RUBBER COATED HARD WASHER
- Кол-во: 1
- Q/SC1294-24
10 G0213001
- G0213001 - PRESSURE LIMITING VALVE COVER
- Кол-во: 1
11 B00001098
- B00001098 - STUD
- Кол-во: 5
- GB/T899-GM10-M10*25-8.8-Y
12 B00000833
- B00000833 - NUT
- HEX FLANGE HEAD CAP
- Кол-во: 7
- GB/T6177-M10-Y
13 S00009457
- S00009457 - GASKET
- Кол-во: 1
14 B00004831
- B00004831 - HEX HEAD BOLT (FLANGED)
- Кол-во: 13
- GB/T16674.2-M14*1.5*40
15 B00000102
- B00000102 - DOWEL
- PIN
- Кол-во: 12
- GB/T119-A12*24
16 76102033A
- 76102033A - BRACKET
- Кол-во: 2
17 B00002161
- B00002161 - HEX HEAD BOLT (FLANGED)
- Кол-во: 2
- Q/SC622-M8*70
18 B00002158
- B00002158 - HEX HEAD BOLT (FLANGED)
- Кол-во: 4
- Q/SC622-M8*65
19 B00004830
- B00004830 - HEX HEAD BOLT (FLANGED)
- Кол-во: 16
- GB/T16674.2-M14*1.5*30
20 G0210503A
- G0210503A - HOUSING
- GEAR
- Кол-во: 1
21 G0213803
- G0213803 - BRACKET
- Кол-во: 2
22 G0211902
- G0211902 - CRANKSHAFT SEAL
- FRONT
- Кол-во: 1
23 G0210601
- G0210601 - GASKET
- GEAR HOUSING
- Кол-во: 1
24 G0210703A
- G0210703A - PLATE
- GEAR HOUSING COVER
- Кол-во: 1
25 G0210803
- G0210803 - GASKET
- GEAR HOUSING COVER PLATE
- Кол-во: 1
26 B00001545
- B00001545 - RUBBER COATED HARD WASHER
- Кол-во: 6
- Q/SC1294-10
27 B00002221
- B00002221 - BANJO BOLT
- Кол-во: 1
- Q/SC642.3-1-M10*1*25
28 S00006214
- S00006214 - ORIFICE ASSY
- PISTON COOLING JET
- Кол-во: 6
29 76102003B
- 76102003B - WASHER SEAL
- Кол-во: 12
30 G0211701
- G0211701 - WASHER SEAL
- Кол-во: 6
31 B00001999
- B00001999 - HEX HEAD BOLT (FLANGED)
- Кол-во: 25
- Q/SC622-M10*25
32 765M02003
- 765M02003 - LIFTING EYE
- Кол-во: 2
33 G0210201
- G0210201 - CYLINDER LINER
- Кол-во: 6
34 B00002139
- B00002139 - HEX HEAD BOLT (FLANGED)
- Кол-во: 2
- Q/SC622-M8*30
35 S00008189
- S00008189 - NUT
- CYLINDER HEAD
- Кол-во: 38
36 S00008188
- S00008188 - BOLT
- CYLINDER HEAD
- Кол-во: 38
37 761W02085A
- 761W02085A - WASHER
- Кол-во: 6
38 761W02064A
- 761W02064A - DOWEL BUSHING
- Кол-во: 6
39 S00011414
- S00011414 - GASKET
- CYLINDER HEAD
- Кол-во: 3
40 B00002134
- B00002134 - HEX HEAD BOLT (FLANGED)
- Кол-во: 10
- Q/SC622-M8*20
45 G0200101
- G0200101 - CYLINDER BLOCK ASSY (MACHINED)
- Кол-во: 1
46 G0211501
- G0211501 - BUSHING
- CAMSHAFT
- Кол-во: 7
47 761G02105
- 761G02105 - WATER DRAIN COCK
- Кол-во: 2
48 G0210309
- G0210309 - FLYWHEEL HOUSING
- Кол-во: 1
49 G0210401
- G0210401 - GASKET
- FLYWHEEL HOUSING
- Кол-во: 1
50 G0211401
- G0211401 - THRUST BEARING
- CRANKSHAFT
- Кол-во: 4
51 G0214401A
- G0214401A - REAR OIL SEAL RING
- CRANKSHAFT
- Кол-во: 1
52 B00000118
- B00000118 - DOWEL
- PIN
- Кол-во: 4
- GB/T119-A5*14
55 B00009148
- B00009148 - HEX HEAD BOLT (FLANGED)
- Кол-во: 38
56 G0211601
- G0211601 - SEAL PAD
- OIL PAN
- Кол-во: 2
57 G0211301
- G0211301 - REAR MAIN BEARING HALF (LOWER)
- Кол-во: 7
58 G0211201
- G0211201 - REAR MAIN BEARING HALF (UPPER)
- Кол-во: 7
59 B00001996
- B00001996 - HEX HEAD BOLT (FLANGED)
- Кол-во: 4
- Q/SC622-M10*20
60 S00010897
- S00010897 - COVER
- CYLINDER BLOCK
- Кол-во: 1
61 G0214701
- G0214701 - GASKET
- Кол-во: 2
62 G0214601
- G0214601 - COVER BOARD
- Кол-во: 2
63 B00001551
- B00001551 - RUBBER COATED HARD WASHER
- Кол-во: 1
- Q/SC1294-22
64 G0212102
- G0212102 - GASKET
- OIL COOLER
- Кол-во: 1
65 G0213303
- G0213303 - LIFTING EYE
- Кол-во: 1
66 B00002062
- B00002062 - HEX HEAD BOLT (FLANGED)
- Кол-во: 4
- Q/SC622-M12*50
67 B00000130
- B00000130 - DOWEL
- PIN
- Кол-во: 2
- GB/T119-A8*20
68 D02A16101
- D02A16101 - CUP PLUG
- Кол-во: 2
69 B00000958
- B00000958 - RIVET
- NAMEPLATE
- Кол-во: 4
- GB/T827-2.5*6-L3
70 S00015872
- S00015872 - NAMEPLATE
- Кол-во: 1
71 B00002137
- B00002137 - HEX HEAD BOLT (FLANGED)
- Кол-во: 18
- Q/SC622-M8*25
72 B00002110
- B00002110 - HEX HEAD BOLT (FLANGED)
- Кол-во: 2
- Q/SC622-M6*10
73 G0200601
- G0200601 - OIL DIPSTICK ASSY (WELDED)
- Кол-во: 1
74 B00001728
- B00001728 - HEXAGON PIPE PLUG
- Кол-во: 1
- Q/SC587.1-M18*1.5
75 G0200201
- G0200201 - FUMES DISPOSAL ASSY
- Кол-во: 1
76 G0200501
- G0200501 - SLEEVE PIPE ASSY (WELDED)
- OIL DIPSTICK
- Кол-во: 1
77 G0217901
- G0217901 - BEDPLATE
- CYLINDER BLOCK
- Кол-во: 1
78 B00001989
- B00001989 - HEX HEAD BOLT (FLANGED)
- Кол-во: 1
- Q/SC622-M10*100
79 G0217301
- G0217301 - CUP PLUG
- Кол-во: 4
80 B00001695
- B00001695 - HEXAGON COUNTERSUNK CONE PIPE PLUG
- Кол-во: 1
- Q/SC584.1-R1/2/B2
81 B00001697
- B00001697 - HEXAGON COUNTERSUNK CONE PIPE PLUG
- Кол-во: 5
- Q/SC584.1-R1/4/B2
82 761G04052D
- 761G04052D - CUP PLUG
- Кол-во: 7
83 B00001993
- B00001993 - HEX HEAD BOLT (FLANGED)
- Кол-во: 3
- Q/SC622-M10*130
84 B00002013
- B00002013 - HEX HEAD BOLT (FLANGED)
- Кол-во: 2
- Q/SC622-M10*50
85 B00002032
- B00002032 - HEX HEAD BOLT (FLANGED)
- Кол-во: 1
- Q/SC622-M10*90
86 B00002030
- B00002030 - HEX HEAD BOLT (FLANGED)
- Кол-во: 10
- Q/SC622-M10*80
87 B00001374
- B00001374 - O-RING
- Кол-во: 1
- GB/T3452.1-14*2.65
88 G0212401
- G0212401 - SLEEVE PIPE
- Кол-во: 1
