Генератор, шкивы, ремень, вентилятор и насос водяной
1 B00005036
- B00005036 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 10
- GB/T16674.1-M10*30-10.9-ZN.D
2 S00009619
- S00009619 - FAN ASSY
- BLOW TYPE
- Кол-во: 1
3 B00004452
- B00004452 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 6
- GB/T16674.1-M10*50-10.9
4 S00009835
- S00009835 - FLANGE
- FAN
- Кол-во: 1
5 B00002047
- B00002047 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 1
- Q/SC622-M12*25
6 B00001803
- B00001803 - BIGGER BLACK WASHERS
- Кол-во: 1
- Q/SC597-12*50
7 B00000244
- B00000244 - ROLLING BEARING
- Кол-во: 1
- GB/T276-6308
8 G1611002
- G1611002 - INTERNAL SPACER
- FAN
- Кол-во: 1
9 S00009659
- S00009659 - BUSH
- FAN
- Кол-во: 1
10 B00000245
- B00000245 - ROLLING BEARING
- Кол-во: 1
- GB/T276-6308-Z
11 B774ZLA16B008
- B774ZLA16B008 - PULLEY
- FAN
- Кол-во: 1
12 B00000836
- B00000836 - HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD
- Кол-во: 4
- GB/T6177-M12-Y
13 S00009832
- S00009832 - SHAFT
- FAN
- Кол-во: 1
14 B00001123
- B00001123 - STUD
- Кол-во: 4
- GB/T899-GM12-M12*30-8.8-Y
15 B00001479
- B00001479 - GREASE FILLING JET
- Кол-во: 1
- JB/T7940.1-M10*1
16 S00009868
- S00009868 - V-BELT
- Кол-во: 1
17 B00002016
- B00002016 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 1
- Q/SC622-M10*55
18 S00009382
- S00009382 - WATER PUMP ASSY
- Кол-во: 1
19 B00002024
- B00002024 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 5
- Q/SC622-M10*70
20 B00004890
- B00004890 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 1
- GB/T16674.1-M10*85-10.9-F
21 S00010438
- S00010438 - BELT TENSIONER AND BRACKET ASSEMBLY
- Кол-во: 1
22 B00001113
- B00001113 - DOUBLE END STUDS-BM=1.5D
- Кол-во: 1
- GB/T899-GM10-M10*65-8.8-Y
23 77221015
- 77221015 - GASKET
- Кол-во: 2
24 S00009383
- S00009383 - WATER PUMP ASSY
- Кол-во: 1
25 B00001099
- B00001099 - STUD
- Кол-во: 12
- GB/T899-GM10-M10*28-8.8-Y
26 B00000833
- B00000833 - HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD
- Кол-во: 12
- GB/T6177-M10-Y
27 S00009962
- S00009962 - V-BELT
- Кол-во: 1
28 B00002012
- B00002012 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 1
- Q/SC622-M10*45-ZN.D
29 S00009961
- S00009961 - ROD-ALTERNATOR
- Кол-во: 1
30 B00001993
- B00001993 - HEXAGON BOLTS WITH FLANGE
- Кол-во: 1
- Q/SC622-M10*130
31 S00004890
- S00004890 - ALTERNATOR
- Кол-во: 1
32 B00004549
- B00004549 - CYLINDRICAL PIN
- Кол-во: 2
- GB/T119-B6*14
33 S00009960
- S00009960 - ALTERNATOR BRACKET
- Кол-во: 1
34 B00005157
- B00005157 - HEXAGON NUTS WITH FLANGE
- Кол-во: 1
- GB/T6177.1-M10-HDAC
35 B00000767
- B00000767 - HEXAGON NUTS
- STYLE 1
- Кол-во: 1
- GB/T6170-M10-10-Zn.D
36 B00001238
- B00001238 - SINGLE COIL SPRING LOCK WASHERS
- NORMAL TYPE
- Кол-во: 1
- GB/T93-10-Zn.D
37 B00001276
- B00001276 - PLAIN WASHER
- Кол-во: 1
- GB/T97.1-10-200HV-ZN.D
