Крышка передняя двигателя S00012155
1 D02B10801B
- D02B10801B - COVER ASSY
- OIL FILLER
- Кол-во: 1
2 D02B10903
- D02B10903 - O-RING
- SCREW CAP
- Кол-во: 1
3 D02B10240
- D02B10240 - COVER
- GEAR HOUSING
- Кол-во: 1
4 D02B10402A
- D02B10402A - CRANKSHAFT FRONT SEAL
- Кол-во: 1
5 T02B10840
- T02B10840 - GOVERNOR BRACKET GASKET
- Кол-во: 1
6 T02B10740
- T02B10740 - GOVERNOR BRACKET
- Кол-во: 1
8 B00000833
- B00000833 - HEX HEAD BOLT
- Кол-во: 2
- Q/SC622-M10*20
8 T02B00140
- T02B00140 - HOUSING
- GEAR(ASSEMBLED)
- Кол-во: 1
8 B00001104
- B00001104 - STUD
- Кол-во: 4
- GB/T899-GM10-M10*35-8.8-Y
8 B00001125
- B00001125 - STUD
- Кол-во: 2
- GB/T899-GM12-M12*40-8.8-Y
8 B00000836
- B00000836 - HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD
- Кол-во: 2
- GB/T6177-M12-Y
8 T02B10140
- T02B10140 - GEAR HOUSING
- Кол-во: 1
8 B00002114
- B00002114 - HEX HEAD BOLT
- Кол-во: 1
- Q/SC622-M6*16
8 B00000611
- B00000611 - HEXAGON HEAD BOLT
- Кол-во: 2
- GB/T5783-M6*25
8 B00001297
- B00001297 - PLAIN WASHER
- Кол-во: 2
- GB/T97.1-6-200HV-Y
8 T02B10302
- T02B10302 - ENGINE SPEED SENSOR BRACKET
- Кол-во: 1
9 D02B10640
- D02B10640 - PTO GASKET
- Кол-во: 1
10 B00000833
- B00000833 - HEXAGON NUTS WITH FLANGE-FINE PITCH THREAD
- Кол-во: 2
- GB/T6177-M10-Y
10 B00002150
- B00002150 - HEX HEAD BOLT
- Кол-во: 9
- Q/SC622-M8*50
11 B00002147
- B00002147 - HEX HEAD BOLT
- Кол-во: 1
- Q/SC622-M8*45
12 S00010775
- S00010775 - NAMEPLATE
- Кол-во: 1
13 B00000958
- B00000958 - NAMEPLATE RIVET
- Кол-во: 4
- GB/T827-2.5*6-L3
14 D02B30001
- D02B30001 - HEX HEAD BOLT
- Кол-во: 15
15 B00002134
- B00002134 - HEX HEAD BOLT
- Кол-во: 3
- Q/SC622-M8*20
16 B00002142
- B00002142 - HEX HEAD BOLT
- Кол-во: 1
- Q/SC622-M8*35
17 D02B10540
- D02B10540 - PLATE
- PTO
- Кол-во: 1
