Детали корпуса редуктора LMDYA-1002200/06
1 Q1841075TF2
- Q1841075TF2 - Bolt M10X75
- Кол-во: 1
2 Q1840816
- Q1840816 - Bolt M8X16
- Кол-во: 6
3 LMEMA1002450
- LMEMA1002450 - Tensioner belt pulley parts
- Кол-во: 1
4 L30001002037
- L30001002037 - Front cover plate
- air compressor
- Кол-во: 1
5 L62001002243
- L62001002243 - Front cover gasket
- air compressor
- Кол-во: 1
- EWP
6 Q1840865
- Q1840865 - Bolt M8X65
- Кол-во: 2
7 QYC19820
- QYC19820 - Screw plug M20X1.5
- Кол-во: 1
8 QYC14920
- QYC14920 - Compound seal washer 20
- Кол-во: 1
- EWP
9 Q340B08
- Q340B08 - Nut M8
- Кол-во: 2
10 Q40308
- Q40308 - Washer 8
- Кол-во: 11
11 Q40108
- Q40108 - Washer 8
- Кол-во: 3
12 L30001002084A
- L30001002084A - Air compressor idle gear seat
- Кол-во: 1
13 A30001002041
- A30001002041 - Idler gear parts
- air compressor
- Кол-во: 1
14 2311002087
- 2311002087 - Idle gear wearing plate
- Кол-во: 1
15 Q1200880
- Q1200880 - Stub M8X80
- Кол-во: 1
16 Q1200885
- Q1200885 - Stub M8X85
- Кол-во: 1
17 YC208B02000F
- YC208B02000F - O-ring 2.65X20
- Кол-во: 1
- EWP
18 Q1840820TF2
- Q1840820TF2 - Bolt M8X20
- Кол-во: 2
19 A30001002085B
- A30001002085B - Idle gear seat bolt
- Кол-во: 1
20 YC208B12500F
- YC208B12500F - O-ring 2.65X125
- Кол-во: 1
- EWP
21 LN1001002251
- LN1001002251 - Fuel injection pump gear cover
22 Q1840820
- Q1840820 - Bolt M8X20
- Кол-во: 16
23 L62001002202
- L62001002202 - Gear housing gasket
- EWP
24 L64DB1002203
- L64DB1002203 - Gear housing cover
- Кол-во: 1
25 YC241235
- YC241235 - Straight pin 12X35
- Кол-во: 2
26 Q150B0828TF2
- Q150B0828TF2 - Bolt M8X28
- Кол-во: 6
27 L62001002204
- L62001002204 - Timing gear housing cover board gasket
- Кол-во: 1
- EWP
28 LN1001002201A
- LN1001002201A - Gear nousing
- Кол-во: 1
29 D301002037
- D301002037 - TDC pointer
- Кол-во: 1
30 Q1840845
- Q1840845 - Bolt M8X45
- Кол-во: 2
31 Q1841450
- Q1841450 - Bolt M14X50
- Кол-во: 2
32 YC209070090FR
- YC209070090FR - Oil seal 70X90
- Кол-во: 1
- EWP
32 YC209C070090PR
- YC209C070090PR - Oil seal 70X90
- Кол-во: 1
- EWP optional
33 J56003800302
- J56003800302 - Locating nut
- Кол-во: 2
34 L63001002206
- L63001002206 - Gear cover gasket
- fuel injection pump
- Кол-во: 1
- EWP
35 L62YS1002205
- L62YS1002205 - Fuel injection pump gear cover
36 Q1840825
- Q1840825 - Bolt M8X25
- Кол-во: 2
37 1501003040F
- 1501003040F - Oil filler cap assy
- Кол-во: 1
38 Q1840870
- Q1840870 - Bolt M8X70
- Кол-во: 2
39 MS40D1002460
- MS40D1002460 - Multi-wedge idle gear subassembly
- Кол-во: 1
40 Q150B0865
- Q150B0865 - Bolt M8X65
- Кол-во: 3
