Коробка раздаточная в сборе B9LF0-1600000.02
1 B83001005044
- B83001005044 - Flywheel bolt
- Кол-во: 7
2 B86001005060
- B86001005060 - Flywheel & gear ring component
- Кол-во: 1
3 Q150B0820
- Q150B0820 - Bolt M8X20
- Кол-во: 10
4 GBT27662052RS1
- GBT27662052RS1 - Deep groove ball bearing
- Кол-во: 1
5 Q40308
- Q40308 - Washer 8
- Кол-во: 30
6 Q40108
- Q40108 - Washer 8
- Кол-во: 30
7 B83001600015
- B83001600015 - Rear oil seal cover
- Кол-во: 1
8 B83001600019
- B83001600019 - Seal O-ring
- Кол-во: 1
- 170
9 B83001600018
- B83001600018 - Rear oil seal cover gasket
- Кол-во: 1
10 YC209B122141PL
- YC209B122141PL - Crankshaft rear oil seal 122 X 141
- Кол-во: 1
10 YC209B122141FL
- YC209B122141FL - Crankshaft rear oil seal 122 X 141
- Кол-во: 1
11 Q18412112TF2
- Q18412112TF2 - Bolt M12X112
- Кол-во: 1
12 B83071600541A
- B83071600541A - Crankshaft gear
- Кол-во: 1
13 B83001600401
- B83001600401 - Transfer case
- Кол-во: 1
14 Q40106
- Q40106 - Washer 6
- Кол-во: 1
15 Q40306
- Q40306 - Washer 6
- Кол-во: 1
16 Q150B0612
- Q150B0612 - Bolt M6X12
- Кол-во: 1
17 6QA11600016
- 6QA11600016 - Cover plate-flywheel case
- Кол-во: 1
18 G80001600110
- G80001600110 - Oil pipe clip subassembly
- Кол-во: 1
19 B83031600140
- B83031600140 - Oil inlet pipe subassembly
- Кол-во: 1
20 6QA61307017
- 6QA61307017 - Hinge bolt
- Кол-во: 1
21 QYC14914
- QYC14914 - Seal washer 14
- Кол-во: 2
22 6105Q1600011
- 6105Q1600011 - Flat pin
- Кол-во: 3
23 YC24B1226
- YC24B1226 - Straight pin 12X26
- Кол-во: 1
24 Q72240
- Q72240 - Bowl-type plug 40
- Кол-во: 1
25 B9LF01600500
- B9LF01600500 - Idle gear part
- Кол-во: 1
26 Q1841240TF2
- Q1841240TF2 - Bolt
- Кол-во: 2
27 5301002029
- 5301002029 - Camshaft end cover
- Кол-во: 1
28 Q618B04
- Q618B04 - Screw plug NPT1/2
- Кол-во: 1
29 B73071600342
- B73071600342 - Transfer case cover plate gasket
- Кол-во: 1
30 B83001600024
- B83001600024 - Transfer case cover plate
- Кол-во: 1
31 Q150B0825
- Q150B0825 - Bolt M8X25
- Кол-во: 19
32 B83001600005
- B83001600005 - Hydraulic pump cover plate gasket
- Кол-во: 1
33 B83001600004A
- B83001600004A - Hydraulic pump cover plate
- Кол-во: 1
34 Q40114
- Q40114 - Washer 14
- Кол-во: 4
35 Q40314
- Q40314 - Washer 14
- Кол-во: 4
36 Q150B1430
- Q150B1430 - Bolt M14X30
- Кол-во: 4
37 Q150B1030
- Q150B1030 - Bolt M10X30
- Кол-во: 8
38 Q40310
- Q40310 - Washer 10
- Кол-во: 8
39 Q40110
- Q40110 - Washer 10
- Кол-во: 8
40 B83001600003
- B83001600003 - Hydraulic pump connecting flange
- Кол-во: 1
41 B83001600002
- B83001600002 - Hydraulic pump connecting flange gasket
- Кол-во: 1
42 G80001600004
- G80001600004 - Adjusting gasket
- Кол-во: 6
- Choose for use after measuring
43 GBT2927212C
- GBT2927212C - Rolling bearing 7212C
- Кол-во: 1
44 B9LF01600561
- B9LF01600561 - Hydraulic pump gear
- Кол-во: 1
45 G80001600026
- G80001600026 - Seal O-ring ¢90
- Кол-во: 1
46 B83001600013
- B83001600013 - Bearing cover
- Кол-во: 1
47 B83001600014
- B83001600014 - Water outlet connecting pipe gasket
- Кол-во: 1
48 B83001600006
- B83001600006 - Water outlet port cover plate
- Кол-во: 1
49 B83001600008
- B83001600008 - Transfer case gasket
- Кол-во: 1
50 Q150B12105TF2
- Q150B12105TF2 - Bolt M12X105
- Кол-во: 2
51 QYC19818
- QYC19818 - Screw plug M18X1.5
- Кол-во: 1
52 G80001600021
- G80001600021 - Cooling nozzle gasket
- Кол-во: 1
53 Q61101
- Q61101 - Open groove tapered screw plug NPT1/8
- Кол-во: 1
54 Q150B0865
- Q150B0865 - Bolt M8X65
- Кол-во: 1
55 QYC14912
- QYC14912 - Compound seal washer 12
- Кол-во: 2
56 QYC9011C12125
- QYC9011C12125 - Hinge bolt M12X1.25
- Кол-во: 1
57 GBT2927211C
- GBT2927211C - Rolling bearing 7211C
- Кол-во: 1
58 G80001600006
- G80001600006 - Idle gear pressure plate
- Кол-во: 1
59 YC208A01800F
- YC208A01800F - O-ring 1.8X18
- Кол-во: 3
60 G80001600007A
- G80001600007A - Idle gear bolt
- Кол-во: 3
61 B83001600011
- B83001600011 - Cover plate gasket
- Кол-во: 2
62 B83001600009
- B83001600009 - Cover plate
- Кол-во: 2
63 Q18412117TF2
- Q18412117TF2 - Bolt M12X117
- Кол-во: 3
64 Q18414117TF2
- Q18414117TF2 - Bolt M14X117
- Кол-во: 2
