Распределитель топлива J5600-1104000
1 L30001104131
- L30001104131 - Connecting pipe bolt
- Кол-во: 6
2 G21001104050A
- G21001104050A - High pressure connecting pipe assembly
- Кол-во: 6
3 J56001104100A
- J56001104100A - High pressure pipe parts
- Кол-во: 1
- EWP
4 QYC9011C12125
- QYC9011C12125 - Articulated bolt M12x1.25
- Кол-во: 2
5 QYC14912
- QYC14912 - Seal ring washer 12
- Кол-во: 4
- EWP
6 J56001104C00BSF1
- J56001104C00BSF1 - CR(Common rail) oil return pipe parts
- Кол-во: 1
- EWP
7 J56001104200E
- J56001104200E - Oil return pipe parts
- Кол-во: 1
- EWP
8 J56001104260
- J56001104260 - Oil return pipe clamp bracket assembly
- Кол-во: 1
9 J56001104900B
- J56001104900B - Oil inlet pipe parts
- Кол-во: 1
- EWP
10 QYC14916
- QYC14916 - Seal ring washer 16
- Кол-во: 8
- EWP
11 QYC9011C1615
- QYC9011C1615 - Hinged bolt M16x1.5
- Кол-во: 2
12 J56001104504B
- J56001104504B - Fuel distributor bracket
- Кол-во: 1
13 Q1841025TF2
- Q1841025TF2 - Bolt M10x25
- Кол-во: 4
14 J56001104541A
- J56001104541A - Fuel distributor
- Кол-во: 1
15 G58001104001
- G58001104001 - Transit joint
- Кол-во: 4
16 Q1840825TF2
- Q1840825TF2 - Bolt M8x25
- Кол-во: 1
17 QYC14910
- QYC14910 - Seal washer 10
- Кол-во: 2
- EWP
18 M30001002701A
- M30001002701A - Bolt with oil hole
- Кол-во: 1
19 J56001104F00ASF1
- J56001104F00ASF1 - Pipe parts
- ECU to fuel pump pipe
- Кол-во: 1
20 J56001104A00SF1
- J56001104A00SF1 - Pipe parts
- fuel distributor to injection pump
- Кол-во: 1
- EWP
21 J56001104400BSF2
- J56001104400BSF2 - Pipe parts
- fuel filter to injection pump
- Кол-во: 1
- EWP
22 J56001104300BSF2
- J56001104300BSF2 - Pipe parts
- fuel pump to filter
- Кол-во: 1
- EWP
23 J56001104C10
- J56001104C10 - Pipe clamp bracket assembly
- Кол-во: 1
24 J56001104080ASF1
- J56001104080ASF1 - Pipe parts
- oil pump to oil rail pipe
- Кол-во: 1
- EWP
25 J56001104205
- J56001104205 - Joint
- Кол-во: 6
26 QYC1498
- QYC1498 - Combined seal washer 8
- Кол-во: 12
- EWP
