Топливопровод в сборе L38DA-1104000
1 L310011041A0B
- L310011041A0B - No.1cylinder high pressure pipe
- Кол-во: 1
- EWP
2 1501104017A
- 1501104017A - joint pipe nut
- Кол-во: 12
3 L30001104131
- L30001104131 - connecting pipe bolt
- Кол-во: 6
4 L30001104129
- L30001104129 - O-ring 10.69x3.5
- Кол-во: 6
- EWP
5 L30001104120A
- L30001104120A - high pressure connector
- Кол-во: 6
6 3301104080
- 3301104080 - clamp fixed assembly
- Кол-во: 3
7 L310011041B0B
- L310011041B0B - No.2cylinder high pressure pipe
- Кол-во: 1
- EWP
8 L310011041C0B
- L310011041C0B - No.3cylinder high pressure pipe
- Кол-во: 1
- EWP
9 L310011041D0B
- L310011041D0B - No.4cylinder high pressure pipe
- Кол-во: 1
- EWP
10 L310011041E0B
- L310011041E0B - No.5cylinder high pressure pipe
- Кол-во: 1
- EWP
11 L310011041F0B
- L310011041F0B - No.6cylinder high pressure pipe
- Кол-во: 1
- EWP
12 QYC9013C10
- QYC9013C10 - Lock Washer 10
- Кол-во: 6
13 L30001104041B
- L30001104041B - Oil return union bolt
- Кол-во: 6
14 L31001104240
- L31001104240 - Oil return parts
- Кол-во: 1
15 L31001104004
- L31001104004 - connector
- Кол-во: 4
- EWP
16 QYC1496
- QYC1496 - Washer
- Кол-во: 12
17 L31001112003
- L31001112003 - Bolt
- Кол-во: 6
18 L31001104400E
- L31001104400E - pipe parts between fuel filter and injection pump
- Кол-во: 1
19 L31001104300E
- L31001104300E - pipe parts between fuel filter and fuel supply pipe
- Кол-во: 1
20 L31001104B00D
- L31001104B00D - pipe parts between fuel distributor and fuel supply pipe
- Кол-во: 1
21 QYC9011C1415
- QYC9011C1415 - link bolt M14x1.5
- Кол-во: 6
22 QYC14914
- QYC14914 - Seal washer 14
- Кол-во: 12
- EWP
23 QYC9011C1615
- QYC9011C1615 - link bolt M16x1.5
- Кол-во: 2
24 L31001104541A
- L31001104541A - fuel distributor
- Кол-во: 1
25 Q40110
- Q40110 - Lock Washer 10
- Кол-во: 2
26 Q40310
- Q40310 - Lock Washer 10
- Кол-во: 2
27 Q150B1020
- Q150B1020 - bolt M10x20
- Кол-во: 2
28 Q40108
- Q40108 - Lock Washer 8
- Кол-во: 2
29 Q40308
- Q40308 - Lock Washer 8
- Кол-во: 2
30 Q150B0840
- Q150B0840 - bolt M8x40
- Кол-во: 2
- EWP
31 G58001104001B
- G58001104001B - Union joint
- Кол-во: 2
32 QYC14910
- QYC14910 - Seal washer 10
- Кол-во: 1
- EWP
33 QYC19810
- QYC19810 - plug M10x1
- Кол-во: 1
34 L31001104504C
- L31001104504C - fuel distributor bracket
- Кол-во: 1
35 L31001104A00D
- L31001104A00D - fuel pump overflow pipe parts
- Кол-во: 1
36 L31001104700D
- L31001104700D - pipe parts between injection pump and fuel distributor
- Кол-во: 1
37 QYC14916
- QYC14916 - Seal ring 16
- Кол-во: 10
- EWP
38 L31001111090A
- L31001111090A - spillover valve
- Кол-во: 1
- EWP
39 JBT6014
- JBT6014 - jacket
- Кол-во: 12
- EWP
