Узел подачи топлива
1 J56001104050
- J56001104050 - High pressure connecting pipe assembly
- Кол-во: 6
2 L30001104131
- L30001104131 - Connecting pipe bolt
- Кол-во: 6
3 LA1001104100A
- LA1001104100A - High pressure fuel pipe parts
- Кол-во: 1
4 Q1841025TF2
- Q1841025TF2 - Bolt M10X25
- Кол-во: 2
5 YC15012E
- YC15012E - Compound seal washer 12
- Кол-во: 4
6 L47001104C00A
- L47001104C00A - Fuel return pipe parts
- common rail pipeline
- Кол-во: 1
7 4301111034
- 4301111034 - Connecting bolt
- Кол-во: 2
8 L47001104G00C
- L47001104G00C - Fuel pipe parts from fuel distributor to ECU
- Кол-во: 1
9 QYC14916
- QYC14916 - Compound seal washer 16E
- Кол-во: 13
10 M40001104304C
- M40001104304C - Connector
- Кол-во: 3
11 YC208B01400F
- YC208B01400F - O-ring 2. 65X14
- Кол-во: 3
12 L47001104F00
- L47001104F00 - Fuel pipe parts from ECU to fuel pump
- Кол-во: 1
13 L47001104300
- L47001104300 - Fuel pipe parts from fuel pump to fuel filter
- Кол-во: 1
14 QYC9011C1010
- QYC9011C1010 - Bolt M10X1
- Кол-во: 1
15 YC15010E
- YC15010E - Compound seal washer 10E
- Кол-во: 2
16 L47001104004
- L47001104004 - Joint
- Кол-во: 3
17 Q1840815TF2
- Q1840815TF2 - Bolt M8X15
- Кол-во: 6
17 Q1840820TF2
- Q1840820TF2 - Bolt M8X20
- Кол-во: 2
18 Q1840835TF2
- Q1840835TF2 - Bolt M8X35
- Кол-во: 1
19 J56001104541C
- J56001104541C - Fuel distributor
- Кол-во: 1
20 QYC9011C1615
- QYC9011C1615 - Bolt M16X1. 5
- Кол-во: 5
21 L47001104240A
- L47001104240A - Fuel return pipe assembly
- Кол-во: 1
22 L47001104400C
- L47001104400C - Fuel pipe parts from fuel filter to injection pump
- Кол-во: 1
23 L47001104700
- L47001104700 - Fuel pipe parts from injection pump to fuel distributor
- Кол-во: 1
24 L31001112003
- L31001112003 - Bolt
- Кол-во: 6
25 YC1506E
- YC1506E - Compound seal washer 6E
- Кол-во: 12
