Амортизатор коленчатого вала в сборе M3001 -1005000
1 M34001005202
- M34001005202 - Fasten bolt
- Кол-во: 6
2 M30011005201C
- M30011005201C - Crankshaft pulley
- Кол-во: 1
3 M34001005240
- M34001005240 - Silicon oil vibration damper parts
- Кол-во: 1
4 M34001005018
- M34001005018 - Camshaft small sleeve
- Кол-во: 1
5 M34001005019
- M34001005019 - Camshaft O-ring
- Кол-во: 1
6 M34001005001B
- M34001005001B - Camshaft
- Кол-во: 1
7 M30001005007A
- M30001005007A - Camshaft thrust plate (upper)
- Кол-во: 2
- EWP
8 M30001005005A
- M30001005005A - Upper main bearing shell
- Кол-во: 7
9 Q2821010T10F9
- Q2821010T10F9 - Bolt
- Кол-во: 6
- M10X10
10 M34001005002C
- M34001005002C - Crankshaft timing gear
- Кол-во: 1
11 M30001005017
- M30001005017 - Camshaft O-ring
- Кол-во: 1
12 M34001005016
- M34001005016 - Camshaft sleeve
- Кол-во: 1
13 YC24B0820
- YC24B0820 - Pin
- Кол-во: 1
- 8X20
14 M30001005006A
- M30001005006A - Below bearing shell
- Кол-во: 7
15 M30001005008A
- M30001005008A - Camshaft thrust plate
- Кол-во: 1
16 M30001005006A
- M30001005006A - Main bearing parts
- Кол-во: 1
16 A31001005018
- A31001005018 - Flat pin
- Кол-во: 1
17 M30001005008A
- M30001005008A - Camshaft thrust below plate
- Кол-во: 2
- EWP
