VALVE, SECTION 6669053

VALVE, SECTION 6669053

VALVE, SECTION 6669053

1 6669053

  • 6669053 - VALVE
  • SECTION
  • Section - Boom Swing - W/Ref. 2-18

2 6665467

  • 6665467 - VALVE
  • SECTION
  • Section - Boom Swing - W/Ref. 2-18

3 6665439

  • 6665439 - BOLT

4 6665442

  • 6665442 - PLATE

5 6665440

  • 6665440 - COVER
  • END

6 6668964

  • 6668964 - CAP

7 6665444

  • 6665444 - BOLT

8 6665446

  • 6665446 - SEAT
  • Spring

9 6665448

  • 6665448 - SPRING
  • Inner

10 6669054

  • 6669054 - SPRING
  • Inner

11 6665447

  • 6665447 - SPRING
  • Outer

12 6669055

  • 6669055 - SPRING
  • Outer

13 6665435

  • 6665435 - O-RING

14 6665445

  • 6665445 - RING
  • BACK-UP

15 6665443

  • 6665443 - RETAINER

16 25K20026

  • 25K20026 - O RING 10
  • Was 6665432

17 73G424

  • 73G424 - SCREW

18 6630965

  • 6630965 - POPPET

19 6665441

  • 6665441 - END COVER

20 6668965

  • 6668965 - CAP

21 6630966

  • 6630966 - SPRING
