TUBELINE 7139953 (2)
1 7139953
- 7139953 - TUBELINE
- - Use W/aux bracket 6597688 3.86" (98 mm) x 4.95" (125.8 mm)
2 6812961
- 6812961 - TUBE
- - Use W/aux bracket 6628560 2.95" (74.9 mm) x 4.72" (119.9 mm)
3 7139954
- 7139954 - TUBELINE
- - Use W/aux bracket 6597688 3.86" (98 mm) x 4.95" (125.8 mm)
4 6812962
- 6812962 - TUBE
- - Use W/aux bracket 6628560 2.95" (74.9 mm) x 4.72" (119.9 mm)
5 6810590
- 6810590 - TUBE
6 6810591
- 6810591 - TUBE
7 6810669
- 6810669 - TUBE
8 6596710
- 6596710 - TUBE
9 6810228
- 6810228 - HOSE
10 6808703
- 6808703 - HOSE
11 6808955
- 6808955 - TUBE
12 42H56
- 42H56 - CLAMP
13 6577697
- 6577697 - CLAMP
- Was 6701893
14 6803909
- 6803909 - HOSE
- for long arm
15 6816626
- 6816626 - HOSE
- for standard arm - Was 6628363
16 6806461
- 6806461 - CLAMP
17 48K16
- 48K16 - O RING 10
18 7246777EF
- 7246777EF - COUPLER FF CONN UNDER PRESS 1/2-3/4 SAE
19 7246777
- 7246777 - COUPLER
- FF MALE
- - straight - Was 6674688
20 6652521
- 6652521 - PLATE
21 6652943
- 6652943 - COVER
- grease fitting
22 6677985
- 6677985 - CLAMP
23 6592506
- 6592506 - CLAMP
24 7246790EF
- 7246790EF - COUPLER FF FEMALE 1/2 BDY 3/4 SAE THREAD
25 7246790
- 7246790 - COUPLER FF FEM 1/2
- - straight - Was 6672960
26 1CM640
- 1CM640 - SCREW HEX CAP
27 1CM860
- 1CM860 - BOLT
28 1CM870
- 1CM870 - BOLT
29 12H15
- 12H15 - FTG GREASE 90
- 90 degree
30 10H25
- 10H25 - FTG GREASE STRAIGHT
31 29CM812
- 29CM812 - BOLT
32 30H30
- 30H30 - CLIP
33 6812823
- 6812823 - ADAPTER
- bulkhead - W/Ref. 30 - flat boss
34 97K12
- 97K12 - O-RING
- flared end
35 99K12
- 99K12 - O-RING
- Tapered boss face
36 79K12
- 79K12 - O RING 10
- Flat boss face
37 6539418
- 6539418 - HOSE
- for standard arm - Was 6628675
38 6809573
- 6809573 - HOSE
- for long arm
39 86F8
- 86F8 - NUT 5
- Use W/flush face couplers
40 6652915
- 6652915 - SEAL
- OIL
- dust
41 6665102
- 6665102 - COVER
42 6666920
- 6666920 - CLAMP
- HALF
43 6810670
- 6810670 - PLATE
- COVER
