CASE ASSEMBLY LH 7258037 (2)

CASE ASSEMBLY LH 7258037 (2)

CASE ASSEMBLY LH 7258037 (2)

1 7258037

  • 7258037 - CASE ASSEMBLY LH
  • W/Ref. 2-4 & 6-15

2 7258038

  • 7258038 - CAMSHAFT ASSEMBLY

3 7258039

  • 7258039 - AUTO COMPRESSION RELEASE ASSEMBLY

4 7258040

  • 7258040 - VALVE
  • INTAKE

5 7258043

  • 7258043 - SCREW

6 7258044

  • 7258044 - SCREW

7 7258045

  • 7258045 - PIN
  • DOWEL

8 7258047

  • 7258047 - TAPPET
  • 4.425

9 7258046

  • 7258046 - TAPPET
  • 4.400

10 7258048

  • 7258048 - TAPPET
  • 4.450

11 7258049

  • 7258049 - TAPPET
  • 4.475

12 7258050

  • 7258050 - TAPPET
  • 4.500

13 7258051

  • 7258051 - TAPPET
  • 4.525

14 7258073

  • 7258073 - TAPPET
  • 5.075

15 7258072

  • 7258072 - TAPPET
  • 5.050

16 7258071

  • 7258071 - TAPPET
  • 5.025

17 7258070

  • 7258070 - TAPPET
  • 5.000

18 7258069

  • 7258069 - TAPPET
  • 4.975

19 7258068

  • 7258068 - TAPPET
  • 4.950

20 7258067

  • 7258067 - TAPPET
  • 4.925

21 7258066

  • 7258066 - TAPPET
  • 4.900

22 7258065

  • 7258065 - TAPPET
  • 4.875

23 7258064

  • 7258064 - TAPPET
  • 4.850

24 7258063

  • 7258063 - TAPPET
  • 4.825

25 7258061

  • 7258061 - TAPPET
  • 4.775

26 7258060

  • 7258060 - TAPPET
  • 4.750

27 7258059

  • 7258059 - TAPPET
  • 4.725

28 7258058

  • 7258058 - TAPPET
  • 4.700

29 7258057

  • 7258057 - TAPPET
  • 4.675

30 7258056

  • 7258056 - TAPPET
  • 4.650

31 7258055

  • 7258055 - TAPPET
  • 4.625

32 7258054

  • 7258054 - TAPPET
  • 4.600

33 7258053

  • 7258053 - TAPPET
  • 4.575

34 7258052

  • 7258052 - TAPPET
  • 4.550

35 7258062

  • 7258062 - TAPPET
  • 4.800

36 7258074

  • 7258074 - TAPPET
  • 5.100

37 7258075

  • 7258075 - TAPPET
  • 5.125

38 7258077

  • 7258077 - TAPPET
  • 5.175

39 7258076

  • 7258076 - TAPPET
  • 5.150

40 7258088

  • 7258088 - TAPPET
  • 5.450

41 7258087

  • 7258087 - TAPPET
  • 5.425

42 7258086

  • 7258086 - TAPPET
  • 5.400

43 7258085

  • 7258085 - TAPPET
  • 5.375

44 7258084

  • 7258084 - TAPPET
  • 5.350

45 7258083

  • 7258083 - TAPPET
  • 5.325

46 7258082

  • 7258082 - TAPPET
  • 5.300

47 7258081

  • 7258081 - TAPPET
  • 5.275

48 7258080

  • 7258080 - TAPPET
  • 5.250

49 7258079

  • 7258079 - TAPPET
  • 5.225

50 7258078

  • 7258078 - TAPPET
  • 5.200

51 7258089

  • 7258089 - CAMSHAFT

52 7258090

  • 7258090 - VALVE
  • EXHAUST

53 7258091

  • 7258091 - SEAT

54 7258092

  • 7258092 - RETAINER

55 7258093

  • 7258093 - RING
  • SNAP

56 7258094

  • 7258094 - SPRING
  • VALVE

57 7258095

  • 7258095 - KEEPER

58 7258096

  • 7258096 - SCREW

59 7258097

  • 7258097 - BOLT
  • Was 7258096
