HOUSING, AIR CONTROL 7016007

HOUSING, AIR CONTROL 7016007

HOUSING, AIR CONTROL 7016007

1 7016007

  • 7016007 - HOUSING
  • AIR CONTROL
  • W/Ref. 2-8

2 7016460

  • 7016460 - BLOCK
  • JETBLOCK ASSY

3 7016026

  • 7016026 - COVER

4 7016031

  • 7016031 - DIAPHRAGM

5 7016710

  • 7016710 - SPRING
  • COMP AIR CONTROL

6 7016087

  • 7016087 - HOUSING
  • AIR CONTROL
  • (MACH)

7 7016276

  • 7016276 - CAP
  • RUBBER
  • 19/64 ID

8 7016632

  • 7016632 - SCREW

9 7016379

  • 7016379 - FILTER

10 7016389

  • 7016389 - FITTING
  • 1/4" NPT TO 1/4" BARB
  • 25" NPT to .25" barbed

11 7016684

  • 7016684 - SOLENOID
  • EV
  • N/C
  • 1/4 DIA

12 7018980

  • 7018980 - CLAMP
  • HOSE

13 7018981

  • 7018981 - SCREW
  • #10-32x3/8 Torx Pan Head
  • Nylon

14 7017529

  • 7017529 - HOSE
  • FUEL BULK/FT
  • bulk - sold per foot
