NUT 6680831 (2)

NUT 6680831 (2)

NUT 6680831 (2)

1 6680831

  • 6680831 - NUT

2 3974971

  • 3974971 - NUT

3 3974972

  • 3974972 - GASKET

4 6655223

  • 6655223 - CAP

5 6684836

  • 6684836 - BOLT
  • assy - W/Ref. 2
  • 3 & 17

6 6685526

  • 6685526 - PLATE
  • CONTROL
  • assy - W/Ref. 7-11
  • 15 & 16 - Was 6684837

7 6684838

  • 6684838 - GOVERNOR

8 6684839

  • 6684839 - LEVER

9 6685476

  • 6685476 - SEAL

10 6598098

  • 6598098 - PIN

11 6684823

  • 6684823 - SPRING
  • Was 6684840

12 6684841

  • 6684841 - GASKET

13 4CM620

  • 4CM620 - BOLT
  • Was 1CM620

14 6652764

  • 6652764 - STUD
  • Was 3974462B

15 7010195

  • 7010195 - BOLT
  • ADJUSTMENT

16 1DM6

  • 1DM6 - NUT
  • Was NSS
