553
/
NUT 1DM6 (3)

NUT 1DM6 (3)

NUT 1DM6 (3)

1 1DM6

  • 1DM6 - NUT

2 6519548

  • 6519548 - CONN BODY

3 6557904

  • 6557904 - FLASHER

4 6665316

  • 6665316 - SWITCH
  • hazard

5 6665315

  • 6665315 - SWITCH HEAD LIGHT
  • headlight

6 6665727

  • 6665727 - LIGHT
  • TURN

7 7228077

  • 7228077 - LIGHT BULB 12V C5W

8 6666568

  • 6666568 - BULB
  • 21W

9 6666563

  • 6666563 - LENS

10 6665728

  • 6665728 - FRT LIGHT
  • front

11 7352849

  • 7352849 - BULB HALOGEN
  • 40W/45W

12 7352849

  • 7352849 - BULB HALOGEN
  • halogen - 12V

13 6666564

  • 6666564 - HOUSING

14 6666565

  • 6666565 - LENS

15 6666566

  • 6666566 - GASKET

16 6666570

  • 6666570 - BULB
  • 40W/45W

17 6665729

  • 6665729 - LIC LIGHT
  • license plate

18 6666569

  • 6666569 - BULB
  • 5W

19 6707672

  • 6707672 - HARNESS

20 6707706

  • 6707706 - MT LIGHT
  • light

21 6707804

  • 6707804 - HOUSING LIGHT
  • light

22 17C508

  • 17C508 - BOLT

23 58G808

  • 58G808 - SCREW

24 6665757

  • 6665757 - TURNLIGHT
  • indicator

25 6664599

  • 6664599 - CONNECTOR 3 PIN
  • 3-pin triangle

26 6664800

  • 6664800 - LOCK SECONDARY
  • 3-pin triangle

27 35C410

  • 35C410 - SCREW HEX HD W/F GR5

28 83D4

  • 83D4 - LKNUT HEX FLG GR8

29 6641178

  • 6641178 - CONNECTOR METRI PACK
  • 2-pin

30 6708824

  • 6708824 - MOUNT

31 6680415

  • 6680415 - HANDLE BLANK
  • LH blank - Was 6705920

32 6707976

  • 6707976 - HANDLE ASSEMBLY
  • L.H. - Also order Ref. 18 & 23

33 6640690

  • 6640690 - PIN

34 6640691

  • 6640691 - TERMINAL

35 6641176

  • 6641176 - SEAL

36 6662257

  • 6662257 - PIN

37 6680447

  • 6680447 - DECAL
  • Was 6677370

38 6702621

  • 6702621 - HANDLE GRIP

39 6641180

  • 6641180 - LOCK METRI PACK
  • Use W/ 2-pin connector

40 6640700

  • 6640700 - LOCK METRI PACK
  • 3-pin

41 6641179

  • 6641179 - CONNECTOR METRI PACK
  • 2-pin

42 6640699

  • 6640699 - CONNECTOR METRI PACK
  • 3-pin

43 6707789

  • 6707789 - LIGHT ASSEMBLY

44 6666568

  • 6666568 - BULB
  • 21W

45 6667887

  • 6667887 - BULB
  • 21/5W

46 6668007

  • 6668007 - SCREW

47 6668010

  • 6668010 - LENS

48 7337673

  • 7337673 - LIGHT WORK
  • LH - Was 7308797

49 7337674

  • 7337674 - LIGHT WORK
  • - RH

50 7109404

  • 7109404 - HARNESS
  • 1524mm [60"] long

51 7110531

  • 7110531 - HARNESS
  • 1282.7mm [50.5"] long - Was 6718198

52 25E11

  • 25E11 - WASHER

53 4DM5

  • 4DM5 - NUT HEXAGON M5

54 6672279

  • 6672279 - MOUNT
  • LIGHT RUBBER
  • rubber

55 6713736

  • 6713736 - BRACKET
  • light switch

56 6714008

  • 6714008 - PIN
  • Bob-Tach - .688" O.D. x 6" long

57 6670668

  • 6670668 - PIN
  • snapper
