GROMMET 565049 (1)
1 565049
- 565049 - GROMMET
2 6515427
- 6515427 - LIGHT
- oil pressure
3 6518763
- 6518763 - SWITCH
- ignition
4 6505412
- 6505412 - KEY 5
5 6512807
- 6512807 - AMMETER
- ammeter
6 6519001
- 6519001 - BREAKER
- circuit
7 667483
- 667483 - CABLE
- battery - Positive
8 6660109
- 6660109 - HOURMETER
- hourmeter - Was 6551203
9 6664886
- 6664886 - METER HOUR
- Was 6631657
10 7312552
- 7312552 - BATTERY 650 CCA DRY
- - Was 6674687
11 6630154
- 6630154 - CAP
- gang - Danger
12 6630155
- 6630155 - CAP
- gang - Poison
13 6514898
- 6514898 - 6 CAPS
- tilt-tite
14 7269859
- 7269859 - BATTERY 650 CCA
15 17C648
- 17C648 - SCREW HEX CAP
16 4E6
- 4E6 - WASHER
17 61D6
- 61D6 - NUT HEX FINISHED GR5
18 17C516
- 17C516 - BOLT
19 4E5
- 4E5 - WASHER
20 61D5
- 61D5 - NUT HEX FINISHED GR5
21 6547125
- 6547125 - TIGHTENER
22 25E15
- 25E15 - WASHER FLAT PLAIN
23 17C524
- 17C524 - BOLT
24 887408
- 887408 - IGN COIL
25 1550963
- 1550963 - SWITCH
- hourmeter
26 6502344
- 6502344 - CLIP
27 17C512
- 17C512 - BOLT 5
28 6555140
- 6555140 - HARNESS
- engine
29 6555558
- 6555558 - HARNESS
- panel
30 908239
- 908239 - VOLT REG
- voltage - Use old mounting bracket - Was 1810770
31 17C416
- 17C416 - BOLT
32 608869
- 608869 - FUSE
- 30 Amp
33 6610510
- 6610510 - STRAP
- TIE 10
- Was 1715312B
34 17C616
- 17C616 - BOLT 5
35 6515603
- 6515603 - GROMMET
36 4E4
- 4E4 - WASHER
37 61D4
- 61D4 - NUT 5
38 6553094
- 6553094 - CABLE
- battery - Negative
39 6505371
- 6505371 - BELT
- ALTERNATOR
40 6502904
- 6502904 - NUT
- ignition switch
