642.0
/
LINK KIT 6571889

LINK KIT 6571889

LINK KIT 6571889

1 6571889

  • 6571889 - LINK KIT
  • bob-tach linkage - Ref. 2-21

2 35C610

  • 35C610 - BOLT 5

3 619021

  • 619021 - WASHER

4 6563106

  • 6563106 - LEVER

5 6503387

  • 6503387 - SPRING
  • Was 6562018

6 6562026

  • 6562026 - INSERT 5

7 6565186

  • 6565186 - BLOCK
  • BOB-TACH WEDGE

8 7D8

  • 7D8 - NUT 5

9 25E21

  • 25E21 - WASHER FLAT PLAIN

10 6578253

  • 6578253 - SPRING
  • COMPRESSION
  • Was 6562018

11 6562019

  • 6562019 - GUIDE

12 6565189

  • 6565189 - WEDGE

13 17C884

  • 17C884 - BOLT

14 6563103

  • 6563103 - COVER

15 6563108

  • 6563108 - ANGLE 5

16 85D6

  • 85D6 - NUT PRETRQ HEX LOCK

17 6565190

  • 6565190 - WEDGE

18 38C810

  • 38C810 - BOLT
  • Was 661846B

19 6563107

  • 6563107 - LEVER

20 743332

  • 743332 - FITTING
  • GREASE 5

21 6570256

  • 6570256 - INSTRUCTIONS
