HANDLE CONTROL 6737524

HANDLE CONTROL 6737524

HANDLE CONTROL 6737524

1 6737524

  • 6737524 - HANDLE CONTROL
  • red square - Was 6668913

2 7D4

  • 7D4 - NUT HEX JAM

3 6707101

  • 6707101 - SEAL NEOPRENE
  • neoprene

4 6706582

  • 6706582 - MOUNT

5 83D5

  • 83D5 - LKNUT HEX FLG GR8

6 17C568

  • 17C568 - BOLT

7 84G3716

  • 84G3716 - SCREW THD ROLLING TT

8 6664850

  • 6664850 - ASSY
  • VALVE
  • lift lock - Also W/Ref. 33

9 6578183

  • 6578183 - TEE
  • W/Ref. 22

10 79K10

  • 79K10 - O RING 10
  • for flat boss face

11 99K10

  • 99K10 - O-RING
  • for tapered boss face

12 15K5

  • 15K5 - FITTING
  • W/Ref. 12

13 79K6

  • 79K6 - O RING 10

14 6708745

  • 6708745 - TUBELINE

15 19K5

  • 19K5 - FITTING
  • W/Ref. 12

16 6587277

  • 6587277 - HOSE

17 6664849

  • 6664849 - VALVE
  • tilt lock solenoid - W/Ref. 18-20

18 7304852

  • 7304852 - VALVE
  • CARTRIDGE
  • W/diode - SEE NOTE - Was 6672471

19 6667687

  • 6667687 - VALVE
  • STEM SOLENOID
  • Was 6665004

20 6671025

  • 6671025 - COIL
  • SOLENOID 08-12
  • W/diode - one red & one black wire

21 6665487

  • 6665487 - SEAL KIT

22 6665489

  • 6665489 - FITTING
  • ADAPTER
  • filter

23 6665612

  • 6665612 - SEAL KIT

24 6665610

  • 6665610 - VALVE

25 6708747

  • 6708747 - TUBELINE

26 17K7

  • 17K7 - ELBOW
  • W/Ref. 12

27 6707369

  • 6707369 - TUBE

28 15K7

  • 15K7 - FITTING
  • W/Ref. 10 - flat boss face

29 15KB1010

  • 15KB1010 - FITTING
  • HYD CONNECTOR
  • W/Ref. 10 - tapered boss face - Was 15KV00007B

30 97K10

  • 97K10 - O-RING 10
  • flared end

31 21K7

  • 21K7 - FITTING
  • TEE
  • W/Ref. 10 - flat boss face

32 21KB1010

  • 21KB1010 - FITTING
  • HYD TEE
  • W/Ref. 10 - tapered boss face - Was 21KN00007B

33 97K10

  • 97K10 - O-RING 10
  • flared end

34 36K7

  • 36K7 - FITTING

35 17C560

  • 17C560 - BOLT

36 6709449

  • 6709449 - VALVMOUNT

37 6709173

  • 6709173 - HOSE

38 6707103

  • 6707103 - CRS 90 UN
  • W/Ref. 10

39 79K12

  • 79K12 - O RING 10

40 6665490

  • 6665490 - VALVE
  • LOCK LIFT
  • manual pull

41 6666828

  • 6666828 - SEAL KIT

42 6665609

  • 6665609 - VALVE
  • CHECK

43 6665611

  • 6665611 - SEAL KIT

44 6667127

  • 6667127 - PLUG
  • W/Ref. 35

45 79K4

  • 79K4 - O RING 10

46 17K3

  • 17K3 - ELBOW

47 17K5

  • 17K5 - ELBOW

48 84G3712

  • 84G3712 - SCREW THD ROLLING TT
