PIN 6564657
1 6564657
- 6564657 - PIN
2 6576302
- 6576302 - LINK
3 95D6
- 95D6 - NUT HEXAGON
4 6563914
- 6563914 - WASHER
- 1" (25.4 mm) OD
5 6665701
- 6665701 - BUSHING
- PRESS FIT
- .89" (22
- 6 mm) OD
6 17C624
- 17C624 - BOLT 5
- grade 8 - 3/8 x 1.5"
7 6665839
- 6665839 - SCREW FLANGED HEAD
8 619021
- 619021 - WASHER
- 0.13" thick - 32 mm (1.25") OD
9 83D6
- 83D6 - LKNUT HEX FLG GR8
10 6708043
- 6708043 - BUSHING FLANGE
- flange
11 6512026
- 6512026 - BUSHING FLANGED
12 37C620
- 37C620 - BOLT CARRIAGE
13 6706104
- 6706104 - NUT RETAINER
14 6544654
- 6544654 - BUSHING
- spacer
15 6717945
- 6717945 - LINK
- flat sides - bushing hole ID .875" (22
- 22 mm)
16 6706105
- 6706105 - YOKE
17 6513495
- 6513495 - PIN 5
18 1306637
- 1306637 - PIN HAIR
19 57D6
- 57D6 - NUT HEX FLNG GR8
20 6726679
- 6726679 - MOUNT
21 6577813
- 6577813 - LINK
- W/slotted holes
22 6717820
- 6717820 - LINK
- W/O slotted holes
23 17C620
- 17C620 - BOLT
24 6708009
- 6708009 - LINK
- 2.69" (68
- 3 mm) long
25 6577961
- 6577961 - GROMMET
26 35C612
- 35C612 - SCREW FLGD HEX CAP
27 6685060
- 6685060 - BUSHING TORSION
- torsion - 26
- 8 mm (1.055") OD - Was 6678067
28 6733942
- 6733942 - LEVER
- notched sides - bushing hole ID 1.0475" (26
- 6 mm)
29 6737388
- 6737388 - WASHER HARDENED
- 1.25" (31.75 mm) OD
30 7115220
- 7115220 - PEDAL MOUNT
31 7115219
- 7115219 - PEDAL
- Was 6726680
32 17C612
- 17C612 - SCREW HEX CAP
33 6557831
- 6557831 - WASHER CONTROLS
- 0.15" thick - 0.88" OD
34 6563914
- 6563914 - WASHER
- 1" (25.4 mm) OD
35 6665701
- 6665701 - BUSHING
- PRESS FIT
- .89" (22
- 6 mm) OD
