MAINFRAME-773G

MAINFRAME-773G

MAINFRAME-773G

1 6717052

  • 6717052 - MAINFRAME-773G

2 6733002

  • 6733002 - MAINFRAME-S185T

3 6711524

  • 6711524 - TAILGATE-GSERIES OLDSTYLE

4 84G3712

  • 84G3712 - SCREW THD ROLLING TT

5 84G3712

  • 84G3712 - SCREW THD ROLLING TT

6 6717278

  • 6717278 - BUSHING
  • WELD-ON

7 6717277

  • 6717277 - BUSHING
  • WELD-ON
  • weld on

8 6717357

  • 6717357 - BUSHING
  • weld on - flat edge

9 6731578

  • 6731578 - BUSHING
  • WELD-ON

10 83D8

  • 83D8 - LKNUT HEX FLG GR8

11 83D8

  • 83D8 - LKNUT HEX FLG GR8

12 6718791

  • 6718791 - COVER

13 7136696

  • 7136696 - COVER
  • Was 6726069

14 6717359

  • 6717359 - BUSHING
  • weld on - bottom upright

15 6731578

  • 6731578 - BUSHING
  • WELD-ON

16 6717358

  • 6717358 - BUSHING
  • weld on

17 6708987

  • 6708987 - HINGE
  • WELD-ON

18 61D6

  • 61D6 - NUT HEX FINISHED GR5

19 6718796

  • 6718796 - PLUG

20 6706808

  • 6706808 - COVER
  • A - 12.80" (325
  • 1 mm) hole pattern

21 6719201

  • 6719201 - COVER
  • MOTOR
  • 13.80" (350
  • 5 mm) hole pattern

22 31C820

  • 31C820 - BOLT

23 31C820

  • 31C820 - BOLT

24 6726062

  • 6726062 - SHIELD

25 6718994

  • 6718994 - MOUNT
  • weld on - solid

26 6732225

  • 6732225 - SPACER
  • hollow - .56" ID

27 37C888

  • 37C888 - BOLT
  • Use W/Ref. 19
