VALVE, CONTROL SERVICE 7229299
1 7229299
- 7229299 - VALVE
- CONTROL SERVICE
- Ref. 2-49
2 29G412
- 29G412 - BOLT
3 54K20002
- 54K20002 - O'RING 10
4 6587763
- 6587763 - BOOT
5 6589564
- 6589564 - RETAINER
- flat
6 1K127
- 1K127 - O-RING 10
- Was 93K127
7 6666588
- 6666588 - SPOOL BOM
- lift - #1 or red - SEE NOTE
8 6666589
- 6666589 - SPOOL BOM
- lift - #2 or green - SEE NOTE
9 6666590
- 6666590 - SPOOL BOM
- lift - #3 or black - SEE NOTE
10 6666593
- 6666593 - SPOOL
- TILT
- tilt - #3 or black - SEE NOTE
11 6666592
- 6666592 - SPOOLTILT
- tilt - #2 or green - SEE NOTE
12 6666591
- 6666591 - SPOOL
- TILT
- tilt - #1 or red - SEE NOTE
13 7300937
- 7300937 - SPOOL AUX
- auxiliary - SEE NOTE - Was 6588074
14 6595706
- 6595706 - VALVE
- CONTROL
- body - Was 6595706
15 6592115
- 6592115 - SEAT
16 6592117
- 6592117 - SPRING
- LOAD CHECK
17 79K8
- 79K8 - O RING 10
18 6592116
- 6592116 - NUT
- load check
19 6683274
- 6683274 - SEAL
- SPOOL 10
- - Was 7031367
20 6589565
- 6589565 - SEAL
- seal
21 6660644
- 6660644 - CAP
22 6662848
- 6662848 - CAP
23 6595663
- 6595663 - BUSHING
24 6588197
- 6588197 - SPRING
25 6537096
- 6537096 - WASHER
26 58K124
- 58K124 - O RING 10
27 79K10
- 79K10 - O RING 10
28 80K14
- 80K14 - BKUP WSH5
- Was 73K000014B
29 58K014
- 58K014 - O-RING 10
- back-up washer required
30 6677106
- 6677106 - O-RING
- back-up washer not required
31 29G416
- 29G416 - BOLT
32 7101345
- 7101345 - BONNET
- DETENT HYD VALVE
- Was 6587633
33 30G416
- 30G416 - BOLT
34 6592109
- 6592109 - ADAPTER
35 6592100
- 6592100 - COLLAR
36 6587580
- 6587580 - SPRING
37 7211397
- 7211397 - WASHER
- SPRING
- Was 6587523
38 799119
- 799119 - RING
39 6592098
- 6592098 - WASHER
40 6589226
- 6589226 - COVER
- END
- 0.63" flange
41 6531270
- 6531270 - SLEEVE
- DETENT
- lift
42 6587575
- 6587575 - ADAPTER
43 6592107
- 6592107 - SPRING
- DETENT 5
44 6592105
- 6592105 - BALL 5
45 6586918
- 6586918 - SCREW
- DETENT
46 6596807
- 6596807 - PLUG
- plastic - 0.46" long
47 6592720
- 6592720 - PLUG
- W/Ref. 23-25
48 6588981
- 6588981 - END CAP
49 6534630
- 6534630 - RESTRICTOR
- .134/.141
50 6532633
- 6532633 - RESTRICTOR
- .150/.157
51 6632279
- 6632279 - KIT
- SEAL
- main relief - Ref. 44 & 47-49
52 7219324
- 7219324 - VALVE
- RELIEF
- W/ O-rings - pressure to be set in field - Was 6686360
53 6816250
- 6816250 - KIT
- SEAL
- - Ref. 2
- 3
- 4
- 6
- 15
- 26 & 41 - for one spool -Was 6803605
54 6809425
- 6809425 - SEAL KIT
- Ref. 13 & 23-25 - Was 6586461
55 6816715
- 6816715 - KIT
- SEAL
- - Ref. 2-4
- 6
- 13
- 15
- 22-26
- 41
- 44 & 47-49 - Was 6596311
