BUSHING 6536164
1 6536164
- 6536164 - BUSHING
2 6536163
- 6536163 - PIN
- Some pins do not have grease holes
3 6534154
- 6534154 - RING
- RETAINER
4 6535912
- 6535912 - HOSE
- for Boom mounted Aux. Lines
5 6536765
- 6536765 - HOSE
- for Arm mounted Aux. Lines - not included in Kit - Order separately
6 6560382
- 6560382 - PIN
- LOCK
7 6534111
- 6534111 - WASHER
- 5
8 7246777EF
- 7246777EF - COUPLER FF CONN UNDER PRESS 1/2-3/4 SAE
9 7246777
- 7246777 - COUPLER
- FF MALE
- - Was 6674688
10 6598757
- 6598757 - COUPLER
- POPPET MALE
- straight
11 6665430
- 6665430 - RING
- BACK-UP
- For Poppet Coupler
12 48K16
- 48K16 - O RING 10
- For Poppet Coupler
13 7246790EF
- 7246790EF - COUPLER FF FEMALE 1/2 BDY 3/4 SAE THREAD
14 7246790
- 7246790 - COUPLER FF FEM 1/2
- - straight - Was 6672960
15 6598758
- 6598758 - COUPLER FF FEMALE
- straight
16 15KB1012
- 15KB1012 - FTG HYD S CONNECTOR
- W/Ref. 11 - Use W/flush face couplers - Was 755055B
17 15K7
- 15K7 - FITTING
- W/Ref. 11 - Use W/poppet couplers
18 18K7
- 18K7 - FITTING
- W/Ref. 11 - for Arm mounted Aux. Lines - not included in Kit - order separately
19 79K12
- 79K12 - O RING 10
- Use W/flush face couplers
20 79K10
- 79K10 - O RING 10
- Use W/poppet couplers
21 6656155
- 6656155 - BULK
- HOSE
- bulk - sold per foot
22 6657379
- 6657379 - BRACKET
- Mounting - For 2500X & 3500X
23 6535313
- 6535313 - WASHER
24 15K8
- 15K8 - FITTING
- W/Ref. 16
25 79K12
- 79K12 - O RING 10
26 6610510
- 6610510 - STRAP
- TIE 10
27 10H25
- 10H25 - FTG GREASE STRAIGHT
28 6720424
- 6720424 - INSTRUCTIONS
